Use is one of the biggest risks to physical collections in a reference library and so it may be a surprise that the Collection Care department supports the recent introduction of self-service photography into general collection Reading Rooms.

Our approach to collection care is underpinned by a risk-based process whereby we balance the risks to collection items against 10 agents of deterioration (Preventive Conservation and Agents of Deterioration), one of which includes use.

At the British Library where the collection accommodates 625 km of storage, the simple act of requesting an item, having it delivered and being able to refer to it in a Reading Room can mean that it has been handled by 5 or 6 people as it moves around the building, or even the country if it is stored off-site in Boston Spa, West Yorkshire. Even with careful handling, this level of movement increases wear and tear over time and the potential for damage.

However, we believe there are benefits to the Reader and the Library in allowing photography for personal reference. If items can be photographed at the desk they are moved less, which minimises wear and tear and the risk of accidental damage.

 Every item is unique and requires special care when setting up for photography.

Many items can be used safely in reading rooms, even if they aren’t in perfect condition. We do have a policy of identifying items which are not fit to issue and have used the launch of self-service photography as an opportunity to reinforce this in staff training. For example, collection items should not be issued if they cannot be handled safely without suffering damage, or further damage, or where there is a risk of loss or partial loss to the item because of existing damage.

Once copyright and other restrictions are considered, decisions on what can be photocopied, photographed or scanned are made based on the condition, format and size of the item and the equipment or method being used to produce a copy. Photography using a mobile, compact camera or a tablet can be a safer form of image capture than photocopying, which requires increased handling. Self-service photography also increases the range of items and materials that can be copied safely as there are fewer restrictions on size and weight compared with photocopying and scanning where the maximum copy size is A4 or A3.

There are, however, risks with self-service photography which also need to be considered. Users may be tempted to take more photographs just because they can, regardless of whether they need them for reference. It is noticeable that when taking photographs, collection items are treated more like objects and the focus is often on obtaining a good image rather than considering the item itself. Photography is good at capturing small details or articles but if people want to refer to whole pages the self-service scanner may be a better option. There are also items which will always present challenges because their size, format or condition makes them unsuitable for any copying.

To address these risks we have listed 10 key points to bear in mind when using and copying collection items. These are included in the video below which provides an overview of self-service photography. The video is also available online here.

In the first phase of self-service photography we have concentrated on photographing printed books, newspapers and periodicals and have a produced a short video explaining how book supports can be a useful tool when taking photographs.

We are now in the process of developing guidelines for the second phase of self-service photography which will extend the service to special collection Reading Rooms where the range of collection formats are more diverse and varied. Again, our starting point is considering the risks and benefits involved in photographing these items and reviewing the collection care videos we produced a few years ago (Collection Care videos).

Sarah Hamlyn, Lead Preventive Conservator

Joel Munsell (14 April 1808 - 15 January 1880) was a United States printer, publisher and author who had the vision to record useful and contemporary information in the field of papermaking during the 19th century in his 1956 publication Chronology of  the Origin and Progress of Paper and Papermaking. Towards the end of his career in 1875, Munsell penned and privately printed some wonderful recollections of his childhood in Northfield, Massachussets, where he was born and educated (1). Following an introduction to the wheelwright's trade by his father, the young Joel Munsell apprenticed for the printer's trade in the office of the Franklin Post and Christian Freeman newspaper in Greenfield, MA, about 12 miles south of Northfield, where he eventually became office foreman.

 Joel Munsell. Credit: History of Albany County New York

In 1826, an eighteen year old Munsell relocated to Troy in New York before making his way to Albany in 1827, where he would remain until his death. Munsell initally gained employment as an office clerk in the book-store of book dealer John Denio (2), and quickly rose up the ranks to become manager - a position he resigned from in order to secure a position as a journeyman printer. While at Denio's Munsell edited and published a semi-weekly paper called the Albany Minerva which he established in 1828.

It wasn't long before Munsell left the bookstore and took up a position as a compositor in a local newspaper where he stayed for six years. By 1836 the young printer had acquired enough money and knowledge to enable the establishment of his own printing business. He purchased a job printing office in Albany where he was publisher and editor of the New York State Mechanic (a Whig campaign paper) from 1841-1843. His publications in 1842 included The Lady's Magazine, The Northern Star and The Freeman's Advocate, followed by The Spectator in 1844, the Guard and Odd Fellows' Journal in 1845, and subsequently the Unionist, the Albany State Register, the Typographical Miscellany, the New York Teacher, the Albany Morning Express and the Albany Daily Statesman. Munsell was also responsible for publishing Webster's Almanac and the New England Historical and Geneological Register from 1861-1864.

 From Bannister's Joel Munsell, Printer and Antiquarian in Albany, New York, image courtesy of the Rare Book Library, New York State Library.

His dedication to typography and hard work led his business to become one of the most suscessful in Albany. His first book, Outline of the History of Printing, was written in 1839, although he is best-known for Chronology of Paper published in 1856, with extended various editions in 1857, 1864, 1870 and 1876.

In 1834, Joel Munsell married Jane C. Bigelow, a marriage which was to last twenty years until her death. They had four children together. Munsell later remarried and wed Mary Anne Reid with whom he had another six children. At the age of seventy-two, Joel Munsell died in Albany, New York, on 15 January 1880. His son, Frank Munsell, succeeded him in the printing and publishing business.

A large Munsell Collection is held at the New York State Library which acquired his extensive collection of notes and books on printing and local history. These notes were later edited and annotated forming an "Historical Series", contributing greatly to the historical literature of this area. Syracuse University's Bird Library holds a number of Munsell editions, and there are also significant Munsell collections at the Albany Institute of History and Art and the American Antiquarian Society of Worcester, MA, both of which Munsell had an active membership with and to whom he sent copies of most of the material he printed throughout his life.

Joel Munsell had a long and distinguished career and to this day is held in high regard in the world of printing and publishing. See references below for more information on his life.

Christina Duffy

References

(1) Joel Munsell, Reminiscences of Men and Things in Northfield as I Knew Them, from 1812 to 1825, Albany, 1875.

(2) Cyclopædia of American Biographies (1903)/Munsell, Joel

(3) Bannister, Henry S. "From the Collector's Library: Joel Munsell, Printer and Antiquarian in Albany, New York." The Courier 11.2 (1974): 11-22.

Places can now be booked on five courses held at the British Library in 2015 covering topics in preservation and collection care for libraries. The programme will be delivered by the British Library in collaboration with West Dean College and are based on those developed by the National Preservation Office and the Preservation Advisory Centre. The courses will focus on Continued Professional Development for professionals, as well as being relevant for students of conservation or similar qualifications. Details on the courses outlined below can be found on the West Dean website.

 The larvae of furniture beetles, Anobium punctatum, attack wooden book boards, shelving, frames and compressed paper. Copyright DBP Entomology

Preserving historic photographs, 4 March 2015, led by Susie Clark at the British Library, £128

Damaged books: first practical steps, 6 March 2015, led by Caroline Bendix at the British Library, £128

Understanding and caring for bookbindings, 23 April 2015 at the British Library, £116

Environment: Effective monitoring and management, 24 April 2015, led by Jane Henderson at the British Library, £116

Disaster response and salvage, 28 April 2015, led by Emma Dadson at the British Library, £128

For more information including course descriptions see the West Dean information page. You can download a booking form here. Completed forms should be returned to [email protected]

The Preservation Advisory Centre (PAC), which had been running similar courses at the British Library, closed on 31 March 2014. The Preservation Advisory Centre supported the preservation of library and archive collections of all types through the provision of preservation management tools, training and information services. All publications and resources have been transferred to the British Library Collection Care webpages, while the PAC website can be found on the UK Web Archive. Preservation booklets covering a range of topics can be downloaded for free here.

Christina Duffy

The conservation team was recently commissioned by the British Library’s Artist in Residence, Rob Sherman, to create a retrospective binding to his specifications. This would form an integral part of his project whilst at the Library and would be exhibited in the ‘Lines in the Ice: Seeking the Northwest Passage’ exhibition. The book would begin life with blank pages which Rob would fill as part of his work, but the binding itself would already have a fictional material history, written by the artist but to be created by Conservation.

As conservators, our usual role is to repair damage, to remove harmful substances and to support weakness whilst preserving the history of an item, so this project proved to be something of a different challenge. One of the most important aspects of our job is to understand the past history of an item from changes to its physical form - its material story - and to preserve aspects of this story by leaving what we can undisturbed and documented. But for this project, we were going to create that story using our knowledge of the materials that we use on a daily basis… and a few unusual ones!



The book’s covering leather was to resemble salmon flesh; it had a groove cut away at the head to accommodate a fishing rod, gold finishing on the boards and spine, marbled paper endleaves and various other features. It was also to have specific damage deriving from fictional events on the Arctic trip - burn damage, ink splashes, cut marks and dents among many.

The challenge for us was immediately clear:

• To design a binding whose structure and components were historically believable but still met the aesthetic needs and specifications of the artist

• To choose appropriate materials which we could manipulate to artificially adopt the ageing characteristics of a book of that age and use

• To ‘age’ the book using a given narrative and for this to be visually convincing to ourselves as experts in the deterioration in books and paper, but also to the public and their expectations of ‘old books’

After initial consultation with Rob, the binding was underway. Paper was selected which could be abraded and cockled but also be worked on by Rob with his inks and watercolours. Samples of toned goatskin were prepared taking inspiration from the raw flesh of salmon and headband silks were selected to match. The sections of the text block were cut unevenly to resemble slipped sections as sewing thread deteriorates and once the fibres at the paper edges were disrupted and roughed up, they were toned with acrylic paints to resemble the typical damage from dust, dirt and handling that we see on a day to day basis.

 The sewn book block is rounded which is an early stage in binding a full leather volume.

The book takes on a rounded appearance which is afterwards given shoulders for the boards to sit against. A pair of heavy boards was made up to compliment the weight and dimensions of the text block and the natural hemp cords were then laced into holes punched into the boards.

 Hemp cords being laced into the board.

Part of the book’s story is that it was made with a ‘V’ cut completely through the front and back boards as well as the paper pages at the head to enable it to be used as a rod rest. Being an unusual request, it posed a problem when turning in the leather around this area. It was solved by paring thin strips to cover the inside edges of the ‘V’ before the main covering took place and again afterwards facing the groove with thin strips of leather to make the covering appear seamless.

 A V-shape is removed from the book block to create a groove where a fishing rod could rest.

The colour of the leather was critical to the success of the project and small sample strips were toned in different strengths so that Rob could pick the one most appropriate to his vision. Natural goatskin leather was chosen for its distinctive grain pattern and a herringbone pattern similar to that found in the flesh of salmon was masked out in places whilst toning to give a suggestion of fish texture in the skin.

 Toned goatskin leather is fitted over the book block.

Some thought was given to the process of distressing so as to achieve an interesting balance between the careful control of materials and the randomness of physical ‘accidents’ like burning and splattering inks.



 Edges are charred using a candle.

The spine area and board edges were toned to take on a ‘dirty’ or discoloured appearance and tidelines and water damage were constructed around the ‘V’, emulating a wet fishing rod being placed there. The leather and labels were abraded and the corners softened to give a sense of wear and tear.

 The final stages involved adding marble paper and toning.

The process of making the new appear old was fascinating. To imagine the book being used within the context of a story and then to create layers of patina and wear and tear which depict that narrative, really made us conscious of how intuitively conservators understand patterns of damage and deterioration.  It has been a really different experience to work ‘in reverse’ and surprising and valuable to discover how much of our knowledge of the deterioration of paper based materials and book structures were required to make the ageing of the Salmon Book appear convincing and yet to do all this without actually physically or chemically damaging the book - a future collection item.

Royston Haward and Zoe Miller

Two Hebrew manuscripts in their original bindings came to the conservation studio as part of our
conservation program. Both texts contain the work of Abraham bar Hiyya (d. 1136) who was a medieval Spanish philosopher, mathematician and astronomer.

Background history

Little is known about bar Hiyya’s life except that he lived in Barcelona. Although there are points of similarity with other medieval thinkers, his writings contain a mixture of Neoplatonist, Aristotelian and Rabbinic ideas, with original interpretations. He was often quoted by later authorities and accepted as authoritative. There was often no distinction between astronomy and astrology in medieval Spanish or Latin text. Astrology was consulted for such things as births, journeys, business and weddings. Abraham was the foremost scientific authority in Spain at this time and he was a firm believer on this aspect of astrology. Many of the terms invented by Abraham have remained current in scientific and mathematic Hebrew to the present (1).

Besides Bar Hiyya’s Tsurat ha-arets which was copied c. 15th century in a Byzantine style of Hebrew writing (ff. 2r-54v), Or 10721  contains  two additional treatises copied by other scribes in the 15th-16th century. The two other works are Torat emet imun by Zecharia ben Mosheh ha-Kohen ha-Rofe (ff. 1r-1v; poetry), and Sefer ha-osher (Book of wealth) a scientific treatise (ff. 57r-61v).

Right board of Or 10721.



Left board of Or 10721.



The first text was written by Abraham bar Hiyya and was one of the first Hebrew texts on cosmography. It is a short review of the ‘lands according to the seven climates’ - the chief source of geographical knowledge among the Jewish community at the time. Abraham bar Hiyya theorised that the Earth was at the very centre of the universe despite conflicting contemporary knowledge. The second text is a translation into rhymes of Bishop Marbod’s text (c.1090) ‘Liber Lapidum’- a tract on the medical and mystical qualities of precious stones. This text also considers astrological principles and the relationship between geology and the positions of heavenly bodies. The third (ff61v-62r) describes the restorative properties of the eagle.

The manuscript is written in iron gall ink and is attributed to a scribe who worked in Italy named Joseph ben Se’adyah Ibn Hayyim.

Or 10538 is a manuscript copied in Italy and dates from approximately the 14th or 15th century. It contains two treaties on astronomy and the Jewish calendar Sefer ha-Ibbur by Abraham bar Hiyya and Sod ha-‘Ivin by Yosef ben Yehudah Hazan.

Right board of Or 10538.



Left board of Or 10538.



This manuscript was copied in Italy approximately around the 14th or 15th century and was censored in the 17th century. Abraham bar Hiyya’s main astronomical work known as Hokhmat ha-hizayon contains two parts; the first part Tsurat ha-arets or ‘Shape of the Earth’, which is included in Or 10721, and the second Heshbon Mahalekhot ha-kokhavim or 'Calculation of the courses of the stars’ which incorporates a whole section on intercalation. The whole work is probably the first exposition of the Ptolomaic system in Hebrew and was the first complete textbook of astronomy in that language. In Or 10538 Abraham further considered the problems of intercalation to enable Jews to observe the festivals on the correct dates (2).

Both volumes contain texts from Abraham bar Hiyya and both have kept their original 14th or 15th century bindings. Even though the binding styles are completely different, they are both unique objects. We decided to take a minimal intervention approach preserving as many of the historic features and characteristics of these manuscripts as possible, and to allow binding features and intricacies individual to these bindings to be visible. Repairs to these volumes would be carried out in-situ, intervening as minimally as possible whilst allowing it to be accessed safely by a guided readership.

Conservation

Or 10721 - There was an increase in book production towards the end of the 15th century when paper became more readily available and also a greater demand for embellishment of finished books as they became more affordable to produce. This meant that binders had to create time-saving methods which led to the adoption of less durable techniques and materials. Despite this, when developing techniques for book conservation today, we can learn a great deal from medieval book structures as their continuing existence is testament to their strong mechanical techniques of production.

Left pastedown before conservation showing alum-tawed supports laced into boards and torn vellum.



When Or 10721 came to conservation it had missing areas to the leather exposing one of the sewing supports, a cracked and abraded surface, and a missing endband. The other endband was present but breaking away from the binding. One sewing support had broken in the gutter at both joints with the boards, which was causing the first and last sections to protrude from the boards (cut flush to the textblock) at the fore-edge.

A number of folios were loose with subsequent tears and crumpling to the edges. Where the vellum pastedowns had come away from the boards a section had torn away and was still adhered to the inner board surface. Rust from the metal bosses had caused burn holes in the first and last few folios, and the volume had surface dirt throughout.



Damage to leather spine: Thread remnants from the tail and head endbands showing damage from use and original lacing into boards.



Some of the damage that has occurred over time has exposed otherwise hidden codicological features which are of interest to the scholarship of bindings of this type. Therefore one factor in the treatment of this item was not to hide this evidence.

The treatment aims for this book were:

• To strengthen and stabilise the sewing structure and its supports
• To reconnect and repair the existing endband (head) and replicate its structure (tail)
• To support and reinsert loose folios and repair vellum pastedown
• To consolidate covering leather

The sewing supports were extended using linen thread which was frayed out and adhered to the wooden board. This repair in addition to repairing and reconnecting the endbands to their cores within the boards helped strengthen the opening of the boards and the connection of textblock to binding. It also helped to ease the sections back into the binding and prevent further damage to the paper where it protruded at the fore-edge.

Or 10721 spine after conservation.



Or 10538 is a manuscript written with iron gall ink on parchment with annotations and foliation in graphite. The binding is limp vellum with the double alum-tawed sewing supports laced into the cover and a foredge flap extending from the left cover. Writing is visible over the covering parchment. The binding has been sewn all along on two double alum-tawed supports with thick linen thread. These supports are crossed and laced into the cover in a triangle pattern. Remnants of alum-tawed ties were observed. There are no spine linings or adhesive on the spine which has a natural hollow. Paper labels are found on the spine and left cover.

We don’t know the exact date of the binding but we do know that limp vellum bindings were commonly used in Italy in the 15th century answering to the increased demands of the time. This is a non- adhesive structure, which relies on strong sewing and materials. On the textblock there are indications that it has been resewn: a central sewing hole is not used in the current sewing and there is evidence of a sewing support in the corresponding place on the spine.

Inside of right board showing alum-tawed supports which have been knotted together.

Inside of left board showing flap.



The covering parchment was severely damaged. Assessment showed that it was cockled, brittle, gelatinised, and stiff, with overall staining and abrasion. There was severe shrinkage and the foredge flap has been folded inside the left cover. The right cover no longer extends to the foredge of the textblock. Shrinkage resulted in tension which has contributed to loss of covering on the spine; 50% of the spine covering was missing. There were losses to the corners of the left cover and foredge flap joint. Paper labels on the spine were torn, lifting, and had losses. The sewing was in poor condition, with broken kettle stitches in the centre at head and tail.

Damage at the spine.

Spine after releasing the supports from the left cover.



The treatment aims for this book were:

• To strengthen and stabilise the sewing structure and its supports
• To repair the vellum cover and infill the losses keeping all the original features

The challenge was to repair the cover without disturbing the lacing paths and undoing the knots. The alum-tawed ties were carefully removed from the right board, leaving the knotted alum-tawed ties of the left board untouched. The spine was then carefully repaired using layers of Japanese papers dyed to match the original colour.

Right board after treatment.

Spine after treatment.



Our approach is always trying not to disturb the codicological features as we can not necessarily anticipate what future research may be looking for. It is always the challenge of book conservators to make items accessible to readers while preserving as much as possible. In this case it has been very satisfying to be able to preserve the individual features of these unique items and make them available to researchers. Of course the books still need careful handling, as they are not only the carriers of content but also of the history of the objects and the history of materials and techniques of the time.

By Mariluz Beltran de Guevara and Zoe Miller

Further reading

(1) Encyclopedia Judaica, Vol 1, 2nd ed, Thompson Gayle, 2007
(2) Medieval Jewish Civilisation, An encyclopaedia, Ed by Norman Roth, Routhledge, 2002

Born on 29 October 1924, legendary bookbinder Bernard Middleton celebrates his 90th birthday this week. Bernard spent much of his life working with British Library collection items at the Library’s bindery, then known as the British Museum Bindery, following his apprenticeship there.



Bookbinder Bernard Middleton at work. Photo courtesy of Bernard Middleton.



Bernard Middleton was interviewed in 2007 for Crafts Lives* by oral historian Hawksmoor Hughes. Crafts Lives is one of the oral history interview programmes run by National Life Stories, the oral history charitable trust based at the British Library. Bernard spoke about his time at the Central School of Arts & Crafts where he gained a general education and a grounding in bookbinding.

Listen to Bernard Middleton on the Central School of Arts and Crafts

“I was very happy there, I liked it.” recalls Bernard, “I liked the fact that my father had been taught in the same room, 25-26 years previously. And I was taught by his fellow student. It was a very good school – it was regarded really as the sort of Oxbridge of the craft world.”

The Central School of Art and Design was established in 1896 and became part of the London Institute almost a hundred years later in 1986. In 1989 it merged with Saint Martin’s School of Art forming Central Saint Martin’s College of Arts and Design, which today has its campus at King’s Cross, just a ten minute walk from the British Library.

The first thing Bernard was taught was how to fold paper, followed by instruction on how to sew a pamphlet , which he describes as “about the simplest thing one can possibly do in bookbinding”. The class learned the history of the way books developed from the scroll to the codex, and gradually took on more complicated bindings including cloth, leather (half-leather, full-leather), and gold-tooling.

Describing himself as “shy” and “well-behaved”, Bernard recalls the odd mischievous day which included throwing balls of wet cotton wool at the ceiling. “I remember throwing one and it hit the teacher in the middle of the back and stuck on his round coat. I was rather embarrassed when he turned around and saw me.”

When Bernard first came to the Bindery there were about eighty workers there and most of his time was spent making end papers. He quickly gained proficiency by working next to journeymen who taught the apprentices their skills. Bernard learned how to bind both old and new books acquired by the Museum’s Library.

Listen to Bernard Middleton on the British Museum Bindery

It was a hard life, with an initial salary of £1 a week and only a seven minute tea break each day: “We had to stand all day and that was hard work when I first went there. We were allowed to sit down for seven minutes at four o’clock to have tea, not in the morning – you had to stand up to have it then…I think it had been five minutes and then two more minutes were negotiated, and then the deputy foreman would bang with a stick on his press to indicate that we should stand up and get on with our work again.”

Bernard’s subsequent career has included managing Zaehnsdorfs, a large and successful binding firm; establishing his own business; researching and writing on the history of bookbinding and restoration; designing and producing approximately 100 original bindings; as well as receiving many commissions from noted collectors, academic institutions and libraries. He was elected a fellow of the Royal Society of Arts in 1951 and received an MBE in 1986.



Bernard Middleton’s 1965 binding on his book A History of English Craft Bookbinding Technique New York & London, 1963. C.108.d.39





Some examples of his bindings are below:

BL shelfmark C.160.c.17



A 1964 binding on Howard M. Nixon, Twelve Books in Fine Bindings from the Library of J. W. Hely-Hutchinson Oxford, 1953. C.160.c.17



BL shelfmark C.188.b.43



A 2004 binding on Marianne Tidcombe, The bookbindings of T.J. Cobden-Sanderson London, c1984. C.188.b.43



More examples of Bernard’s bindings can be seen at the St Bride Library off Fleet Street in London from 27 October to 14 November, 2014.

“My designs are intended to please the eye, not engage the intellect, principally by the employment of textures, strongly defined shapes and contrasts, and by the play of light on gold, preferably in combination and in a manner which complements the book." Bernard Middleton, Recollections (London, 2000), p.85.

With thanks to Philippa Marks (Curator, Bookbindings) and to Mary Stewart (Curator, Oral History) who edited the audio clips.

*Since the Crafts Lives project started in 1999, over 130 in-depth life stories have been recorded with British craftspeople, exploring both their personal lives and their work in the fields of pottery, glass, metalwork, jewellery, textiles and book arts. In August 2014 over 80 of these interviews were made available to listen to online in their entirety – including 13 craftspeople that work in the area of book arts, bookbinding and letter cutting. Visit http://sounds.bl.uk/Oral-history/Crafts to find out more.

Hardly noticeable and barely bleeding, paper cuts are the mother of all library injuries. Anyone who deals with paper on a daily basis will have at some point suffered such an affliction. Paper cuts cause a seemingly out of proportion amount of pain due to the anatomy of our skin and the structure of paper. When very thin and held in place, a sheet of paper becomes inflexible and can exert very high levels of pressure – enough to slice through flesh! Yikes! Let’s go under the microscope to see what's happening...

Figure 1: A single sheet of paper at x30 magnification.

Figure 2: Paper cuts - small but mighty!

Most paper cuts result from new sheets of paper held strongly in place. A rogue sheet may come loose from the pack but remain held in position by the rest of the tightly-knit sheets. In paper, more resistance is felt when a force is applied parallel to a sheet of paper. This has to do with the paper’s tensile strength. Tensile strength measures the ability of a material to resist rupture when force is applied to one of its sides under certain conditions. Held in place, the sheet of paper becomes extremely resistant to buckling, stiffens, and acts as a razor.

Figure 3: A sheet of paper that strays from the pack can cause serious paper cuts!

A paper’s edge may appear to be smooth and flat, but on a microscopic scale paper edges are jagged. Paper cuts leave a wound more like one from a saw than a knife (a miniature papery saw).

Figure 4: Pages from a copy book at x30 magnification. Fibres at the surface give paper a serrated edge. The black lines are page lines.

Paper cuts are remarkably painful. They usually occur in the fingertips, which have a greater concentration of nerve cells (neurons) than the rest of the body – an evolutionary trait to protect us during the exploration of our environment. Neurons send chemical and electrical signals to our brain, and some of them, called nociceptors, detect potential harm. Paper cuts stimulate a large number of nociceptors in a very small area of the skin. Shallow paper cuts don’t bleed very much so pain receptors are left open to the air resulting in continuous pain as the wound cannot clot and seal. As we continue to use our hands, the wound flexes open, continually distressing these neurons.

Not only do paper cuts part the flesh with a micro-serrated paper edge, but they also damage skin either side of the wound due to the composition of the paper. Pain receptors are continuously irritated by the combination of cellulosic wood pulp, rags, grasses, chemically-coated fibres, and bacteria that make up paper. Paper may also include other additives such as chalk or china clay to make the paper easier to write on. Sizing gives us a great variety of papers to suit the specific type of ink we wish to apply, but involves mixing many additives into the pulp to determine the correct surface absorbency.

Paper cuts from envelopes can be particularly stingy due to the layer of glue along the sealing tab. The glue is made from gum arabic, which although edible to humans, can pack a punch if embedded inside a wound. Gum arabic is the product of hardened sap taken from two species of acacia trees, and is also used as a binder for watercolour painting, and in traditional lithography.

Figure 5: Gum arabic glue at x30 magnification coats the paper tab on an envelope.

Figure 6: Gum arabic glue at x200 magnification coats the paper tab on an envelope. When the gum is moistened it forms a seal with the adjacent paper.

When skin closes around the paper cut these foreign particles become trapped inside causing a great deal of pain. This is why a cut from a razor blade is usually less painful than that from a paper cut: razor blades make clean incisions without leaving behind any foreign particles. It hurts initially, but the pain soon ebbs away. Bleeding caused by a razor cut helps to wash away any infection-causing particles, while paper cuts bleed very little (this also reduces your chances of getting any sympathy!)

Figure 7: A razor blade at x50 magnification.

Figure 8: A razor blade at x200 magnification. The razor’s edge is smooth allowing a clean incision without introducing foreign bodies.

It might seem strange that sometimes needles for a flu jab require quite a bit of force to pierce the skin, yet paper (PAPER!) can slice through. This is due to the random orientation of collagen fibres in our skin allowing us to withstand pinpoint forces.

Figure 9: Human skin feeling the pressure under a sharp pin (x20 magnification).

Our skin does not have a comparable strength against shearing forces such as those exerted by paper, and so, we are susceptible to the small but mighty paper cut. Libraries can be dangerous places. Be careful out there!

Christina Duffy (@DuffyChristina)



Further learning:

Paper May Be the Unkindest Cut, Scientific American, Volume 306, Issue 3 , Mar 1, 2012 |By Steve Mirsky

Why Do Paper Cuts Hurt So Much? Scientific American - Instant Egghead #25



With the recent multispectral imaging of the burnt Magna Carta hitting the headlines following our blog post on the 800 year old Magna Carta revealing its secrets, there has been a lot of interest in the conservation work required to protect such items. The so-called “burnt” Magna Carta (Cotton charter xiii 31a) suffered fire damage in Ashburnham House in Westminster on 23 October 1731. This 1215 exemplification formed part of an exquisite library assembled by English antiquarian Sir Robert Cotton during his lifetime (1571-1631). Cotton’s library forms the basis of our collections at the British Library today, and a recent conservation survey of the burnt material has allowed us to categorise items based on their relative condition, enabling us to immediately identify items suitable for digitisation. This has vastly improved our workflow allowing digital access to a wider audience in a shorter time.

This piece includes material from an article published by Taylor & Francis Group in Journal of the Institute of Conservation on 29 November 2013, available online at: http://www.tandfonline.com/doi/abs/10.1080/19455224.2013.815122#.VFDzZvmsWtB.

The burnt 1215 Magna Carta suffered fire damage and subsequent interventive treatment. The vulnerable wax seal of the charter melted and distorted in the intense heat.



In the Ashburnham House fire a quarter of the manuscripts were either damaged or destroyed in the blaze, and attempts to extinguish it exacerbated that damage. The documents suffered shrinkage and distortion, bindings were carbonised, ink was lost, soot and dirt was ingrained, tide marks formed on the leaves, and parchment (animal skin) gelatinised. Gelatine is the brownish end-product of a rapid degradation of parchment collagen. Remedial work caused further damage with many of the manuscripts broken up and rebound during salvage. Incorrect reassembly impacted on the codicological history of many of the manuscripts. The darkened gelatinous material which formed along the edge of the parchment was trimmed away from some manuscripts. Unidentified fragments were gathered and put into drawers.

The collection was untouched until the establishment of the British Museum in 1753, where over the coming years invasive treatments were recorded. To separate the leaves which had glued together by gelatinisation, about 40 manuscripts were immersed in a hot aqueous solution (likely to be ethanol in water). Incisions along the parchment edges were made to allow the leaves to dry flat under pressure. Despite the efforts, leaves remained brittle and fragile. Inlaying of parchment fragments into paper was completed in 1856, but a huge number of fragments remained loose and unidentified. While the edges of loose fragments were protected by this inlaying method, over time the degradation of materials caused further concern. The brittle fragments were susceptible to break with every page turn, and acidic paper in heavy volumes tended to cockle preventing the volumes from closing.

Cotton Tiberius A. XII. Parchment fragments were attached to paper in the nineteenth century and incisions were cut along the sides to allow the leaves to lay flat.



Our conservators surveyed 243 items from the Cotton Collection, including 21 paper manuscripts. Items were graded on their physical, chemical and overall conditions based on an assessment of the state of the binding and parchment substrate, and thus rated for treatment priority.

Results of the survey of 243 Cotton Collection volumes. From Figure 2 and 5 in The conservation of the burnt Cotton Collection in the Journal of the Institute of Conservation, 2013

Pattern of damage where D (High degree of damage) accounts for 61% of the total items examined. From Figure 2 and 5 in The conservation of the burnt Cotton Collection in the Journal of the Institute of Conservation, 2013.



The nineteenth century treatments have been fundamental to the preservation of the Cotton Collection, and many items thought to be lost have since been rediscovered. The condition survey enabled us to quantify the damage and develop a strategy for the long-term preservation of the burnt Cotton Collection. Items identified as being fragile were immediately withdrawn from library use, while research to determine the best methods of stabilising and housing the items was undertaken. The use of analytical techniques such as near-infrared (NIR) spectroscopy for assessing the deterioration or parchment has enabled a better awareness of the nature and condition of these manuscripts. This information has helped to support the choice and realistic scope of conservation methods. In the case of the burnt Cotton Collection, the future project is now directed towards a preservation approach, including digitisiation and multispectral imaging, rather than an interventive conservation one.

Christina Duffy (@DuffyChristina), Imaging Scientist



Further reading

The conservation of the burnt Cotton Collection, Mariluz Beltran de Guevara and Paul Garside, Journal of the Institute of Conservation, 2013. Vol. 36, No. 2, 145 –161, http://dx.doi.org/10.1080/19455224.2013.815122

Collection Care fired up for BBC Four appearance, Christina Duffy: http://britishlibrary.typepad.co.uk/collectioncare/2013/08/collection-care-fired-up-for-bbc-four-appearance.html

Crisp as a Poppadom, Ann Tomalak: http://britishlibrary.typepad.co.uk/digitisedmanuscripts/2013/02/crisp-as-a-poppadom.html

‘Their Present Miserable State of Cremation' the Restoration of the Cotton Library, Andrew Prescott: http://www.uky.edu/~kiernan/eBeo_archives/articles90s/ajp-pms.htm

Ground-breaking multispectral imaging work of the British Library’s burnt copy of the 1215 Magna Carta has recovered text which has not been read in 250 years.

This work has been completed by British Library conservators and scientists in preparation for next year’s 800th anniversary of the sealing of the Magna Carta. The so-called ‘burnt’ copy of the Magna Carta is one of four original manuscripts from 1215 which survive. In February 2015, the four manuscripts will be brought together for the first time in history for a special 3-day event, which will allow further academic study of them side by side, as well as the once-in-a-lifetime opportunity for 1,215 people to view them together.



Figure 1: Top left: The “Burnt Magna Carta” ready for multispectral imaging. Top right: A real colour image of a section of the charter. Bottom: A processed image of the charter enhanced to reveal text thought to be lost.

The British Library owns two of the original 1215 Magna Carta manuscripts (the other two are held at Lincoln and Salisbury Cathedrals). The story of the ‘Burnt Magna Carta’ (Cotton charter xiii 31a) held in our collections is a truly remarkable one of survival against all the odds. In 1731 it was damaged in the Cotton Library fire, and subsequently staff at the British Museum Library used 19th century techniques to try to flatten and mount it, which has contributed to its current condition today rendering the text very difficult to see.

The multispectral imaging of the burnt Magna Carta was conducted as part of a major project involving the reframing and scientific analysis of all the Magna Carta charters held in our collections ahead of the 2015 anniversary. The Collection Care team provided an initial examination of the original frames to determine their structure and composition. All original mounting materials in contact with the charters were tested using infrared spectroscopy, pH tests, and lignin tests to determine their stability and compatibility with new materials. Once the charters were removed from the frames, near-infrared spectroscopy and high resolution digital microscopy was used to investigate the condition of the ink and parchment as part of the overall condition assessment.

With the frames and glass removed there was a rare opportunity to employ the cutting-edge technique of multispectral imaging enabling us to virtually peel away the layers of damage currently affecting the manuscript.




Figure 2: Clockwise from top: Temporary housing is prepared to store the charter when removed from the frame; the original wooden frames are removed to enable access to the charter; the charter is released from the mounting; once the charter is free from the frame it can undergo condition assessment.



Figure 3: Left: The “burnt” copy of the Magna Carta, Cotton charter xiii 31a, is one of the four original manuscripts from 1215 which survive. Right: Much of the ink has been lost with only a few remaining initials (shown here at 50x magnification).

Multispectral imaging is a non-destructive, non-invasive imaging technique using different colour lights, including ultra-violet and infrared, to recover faded and lost text. A high-resolution camera is securely mounted directly over the charter, which is then illuminated with LED lights ranging from the ultraviolet at a wavelength of 365 nm, through the visible region, and right up to a wavelength of 1050 nm in the infrared region. The chemical composition of the material in the charter is varied (ink, parchment, etc.), and so reacts differently to the lights. We are able to see, and capture, additional information undetectable by the human eye.

Figure 4:  An animated gif comparing the original colour and processed images.

Figure 5: A colour UV image reveals regions of text which are completely faded to the naked eye.

Using this technology and expertise available to us in the 21st century, we are able to preserve the Magna Carta for the next 800 years and present these iconic documents in the best possible condition for visitors who come to see them during the anniversary year.

Multispectral data is still being processed and will be published along with other scientific data collected after the British Library’s exhibition ‘Magna Carta: Law, Liberty, Legacy’, which runs from 13 March – 1 September 2015.



Christina Duffy (@DuffyChristina), Imaging Scientist

The British Library has partnered with West Dean College to deliver a programme of training in support of conservation and preservation activities in libraries and archives. The courses will be based on those developed by the National Preservation Office and the Preservation Advisory Centre and will focus on Continued Professional Development for professionals. Training will also be relevant for students undertaking conservation or similar qualifications.

Alasdair Ball, Head of Collection Management at the British Library signing the agreement with West Dean College.



The Preservation Advisory Centre (PAC), which had been running similar courses at the British Library, closed on 31 March 2014. The Preservation Advisory Centre supported the preservation of library and archive collections of all types through the provision of preservation management tools, training and information services. All publications and resources have been transferred to the British Library Collection Care webpages, while the PAC website can be found on the UK Web Archive.

The new agreement with West Dean College was signed on 23 September 2014 by Alastair Ball, Head of Collection Management at the British Library, and Peter Pearce, Chief Executive of West Dean College. Ball: "The British Library is delighted to enter into this agreement with West Dean College. The public sector often works at its best when it engages in trusted partnerships with highly respected organisations and this is an excellent example. We look forward to seeing the partnership sustain the provision of high quality professional development for this important sector."

Left to right: Francine Norris, Director of Education at West Dean College; David Dorning, Conservation of Books Programme Leader at West Dean College; Cordelia Rogerson, Head of Conservation at the British Library; Peter Pearce, Chief Executive at West Dean College and Alasdair Ball, Head of Collection Management at the British Library.



West Dean College have been running a Professional Conservators in Practice programme for sixteen years. Peter Pearce: “This partnership brings together two organisations recognized for their expertise. This programme is the perfect complement to West Dean College’s existing range of conservation courses which are internationally renowned. We are excited to benefit from the British Library’s pre-eminent reputation in the care of books”.

West Dean College also offers a full time postgraduate Conservation of Books and Library Materials programme. For further information about the College’s conservation programmes please visit www.westdean.org.uk/college.

Christina Duffy
