Flavio Marzo, Conservation Studio Manager for the British Library/Qatar Foundation digitisation project reports on the conservation of three manuscripts from the India Office Records.

A new conservation studio has been set up at the British Library to support a digitisation project as part of the British Library Qatar Foundation Partnership programme. The Library’s Arabic material has been scoped for the creation of a new web portal where, in a year’s time, around 500,000 images will be made available online to the general public.

Front left board of MS IOR/R/15/1/105

The majority of material identified for digitisation comes from the India Office records. Many of the files that form this collection are related to the Gulf area, and so are deeply connected to the history of Qatar and its neighboring countries.

The India Office Records are a very large collection of documents relating to the administration of India from 1600 – 1947, the period which spans Company and British rule in India. The archive is held here at the Library and is publicly accessible.

As the formal document of British presence in the Persian Gulf, IOR/R/15 is a fascinating series within the India Office Records, giving a unique insight into a colonial encounter between European imperial power and tribal shaikhdoms on the Arabian Peninsula coast.

One of the most striking features of these Records is the variety and mixture of formats and features related to different manufacturing techniques. These range from bound printed or manuscript volumes to folders containing loose leaves, folded maps, photographs, miscellaneous textile offcuts and samples of products sold in the colonies during the English occupation. In many cases these records were produced by a local workforce in the countries where the IOR officers were stationed.

This mixture of local craftsmanship and foreign taste (and in some cases even foreign materials) has produced very interesting objects which carry a fusion of western appearance and “Islamic” manufacturing techniques.

In this post I want to present some features of three bound manuscripts from the India Office Records: IOR/R/15/1/105, IOR/R/15/103 and IOR/15/1/161.

Front left board of MS IOR/R/15/1/161

Front left board of MS IOR/R/15/1/103

These manuscripts were produced in the middle of the 19th century and contain collections of letters sent from the British Political Residency in the Persian Gulf stationed at Bushire (or Bushehr) on the south western coast of Iran.

Many of the features of these volumes are traditionally considered to be Western. They were all bound in full leather and decorated with similar finishing tools without the use of gold (blind tooled decoration).

Detail of the tool used to decorate the cover of two of the manuscripts

Detail of the tool used to decorate the cover of two of the manuscripts

They are written in English on western handmade paper. The countermark in the image below indicates that the paper was produced in 1843 in Stowford Mill, which continues to make paper to this day.

Page from one of the volumes, photographed in transmitted light to reveal the countermark

Other aspects of these books have been produced using ‘Islamic’ style binding techniques. For example, the textblock sections are secured with ‘unsupported sewing’. The Western binding technique of using a material (vellum or cord) to sew around, attaching the sections to it using the thread, is absent here meaning that it is only the thread itself securing the sections together.

Another example is the execution of the endbands that you see in the images below. These are typical of Islamic bindings as commonly recognized in the field of the history book by the way they are sewn and by the final pattern and appearance.

Islamic style endband

Islamic style endband

It is clear from this mixing of binding influences that these volumes were not produced in a Western bindery! It is likely that the materials were provided by the India Office, along with specific requests regarding the appearance, which tie in with traditional Western tastes. The rest was down to the knowledge and expertise of the local binders, and what an exciting interesting fusion of styles it has resulted in!

The writing close to the gutter of the book can make it difficult for digitisation.

In these specific cases, we re-housed the books in custom made archival boxes and repaired enough of the damaged paper and boards to stabilise it for future handling.

They will soon be fully digitized and available online on the Qatar National Library web site. The process of digitisation gives conservators the opportunity to assess large numbers of items in a short period of time, enabling them to more fully understand the collection. In this case, it allowed me to appreciate the fusion of binding styles that make these items so interesting. Their content will be made available and their peculiar and unique features will be preserved.

The final product!

Flavio Marzo

Purple coloured pages of vellum are sometimes found in sacred texts adorned in gold or silver lettering. They can be seen in folios 2-5 of the recently digitised Cotton Titus C XV on the British Library's Digitised Manuscripts website. Fragments of the Codex Purpureus Petrolpolitanus (a 6th century copy of the Four Gospels in Greek) demonstrate the use of purple as an indicator of wealth, power and kingship. Purple parchment was once only used for Roman or Byzantine Emperors, but later found use in Anglo-Saxon illuminated manuscripts for the Emperors in Carolingian art and Ottonian art. The discovery of shell fragments in archaeological sites in Scotland and Ireland has pointed to the harvesting of sea snails for a gland which produces the purple colour.

Figure 1: Fragment of the Codex Purpureus Petropolitanus, 6th century, Cotton MS Titus C XV, f. 4v. Read more about this codex on the BL Medieval blog: A Papyrus Puzzle and Some Purple Parchment.

In 1992 marine shell remains were recovered from caves in Sutherland County in Scotland. Archaeologists used sieves to isolate shells of the whelk known scientifically as Buccinum undatum. These whelks survive in shallow water (down to about 100m) and are found in sand and mud. Their usual capture occurs using baskets or baited pots. The fragmented state of the shells dispersed around the site suggested that they had been purposely collected and broken.

Figure 2:  The sea snail Buccinum undatum.

Another type of whelk mollusc, known as Nucella lapillus (dogwhelk or Purpura lapillus) was found at the Scottish site in Wetweather Cave. Nucella lapillus are found in crevices around rocky shores and estuarine conditions. They are a species of predatory sea snail found around the coasts of Europe and in the north west Atlantic coast of North America where they feed on barnacles and mussels. The deliberately broken shells indicated to researchers that the whelks, which are not edible and were not being used as fishing bait, were being gathered for the production of purple dye.

Figure 3: Nucella lapillus feeding on barnacles.

Nucella lapillus was also found in Connemara in the West of Ireland in 1919 by J. Wilfred Jackson. Heaps of shells (referred to as Purpura-mounds) had previously been found in 1895, but Jackson noted that the shells had deliberately broken apical whorls (a whorl being a turn of the whelk's spiral shell), but the lower whorl with the mouth had been left intact. The shells were smashed in such a way as to retain the cumella allowing the beast to be removed easily. It was clearly a serious business with one of the Irish Purpura-mounds measuring about 50 by 14 m  - over 200 whelks were found in a single square foot!

The dye is comprised of a mucous secretion from the sea snail's hypobranchial gland and is an organic compound of bromine. The secreted fluid is released by the sea snail as a defence mechanism when agitated. The secretion can be collected by "milking" the sea snails, however this is a very labour intensive process and more often than not the snails are crushed instead. It can take thousands of snails to produce a single gram of pure dye. After salting, boiling and sitting for a few days the gland fluid begins to turn from a pale cream to a purple colour. This process is accelerated by sun exposure. After about 10 days the dye is ready for use.

Figure 4: A purple parchment page of the 6th century Codex Argenteus with gold and silver lettering.

Christina Duffy  (@DuffyChristina)

Further reading

Pollard, Tony (2005) 'The excavation of four caves in the Geodha Smoo near Durness, Sutherland'. Scottish Archaeology Internet Report 18

Jackson, J.W. (1917) 'Shells as Evidence of the Migrations of Early Culture'

Henderson, George, Vision and Image in Early Christian England, Cambridge University Press, 1999, paperback edition 2010, Chapter 3, pp.122-135, 'The Colour Purple: A Late Antique Phenomenon and its Anglo-Saxon Reflexes'.

As an Imaging Scientist it is very difficult to look at ordinary objects without wondering what they would look like under a microscope. This was just the case when shown a beautiful printing block with a portrait of Steve Fairbairn, founder of the Head of the River Race, etched on the front. Printing blocks like these were used alongside similar-sized blocks containing type in a printing press to commercially produce images and text for publications. But how does it work?

The Fairbairn printing block, belonging to Pauline Churcher of Thames Rowing Club, consists of type metal (lead, tin and some antimony) with a copper electrolytic layer attached with steel screws to a 21 mm thick wooden block

The Fairbairn printing block, belonging to Pauline Churcher of Thames Rowing Club, consists of type metal (lead, tin and some antimony) with a copper electrolytic layer attached with steel screws to a 21 mm thick wooden block

The traditional printing method of letterpress is capable of printing solid colour from printing plates. In order to convey an image with varying shades and tones using a single colour, a reprographic technique called halftone is used. Halftone simulates continuous tone through the use of dots of various sizes, shape and spacing. The image is broken up into many small solid areas for printing. This gives the illusion of a continuous tone – but if we look up-close, we can see that the image is just an intricate pattern of dots.

Halftoning and halftoning close up: A series of dots of various sizes creates an optical illusion of continuous tone when viewed from a distance

This pattern is created using a printing block with tiny holes etched into a metal plate where ink can sit and be transferred onto paper. Below we see what the Fairbairn printing block looks like at 20x, 50x and 200x magnification.

The Fairbairn printing block at 20x magnification. These three images show the increasing magnification of halftone detail on the printing block (top 20x, centre 50x, bottom 200x). Ink is brushed over the plate and fills the hollows.

The Fairbairn printing block at 50x magnification. These three images show the increasing magnification of halftone detail on the printing block (top 20x, centre 50x, bottom 200x). Ink is brushed over the plate and fills the hollows.

The Fairbairn printing block at 200x magnification. These three images show the increasing magnification of halftone detail on the printing block (top 20x, centre 50x, bottom 200x). Ink is brushed over the plate and fills the hollows.

Before the inception of halftone printing, images were printed in books and periodicals using hand engraved metal plates or wood blocks. Wood engraving involves working an image or group of images into a block of wood for use as a printmaking and letterpress technique. Ink is applied to the face of the block and paper is pressed against it.

In ordinary engraving such as etching, a metal plate is used and is printed by the intaglio method where the ink fills the removed areas. When the excess ink is wiped away a sheet of paper is placed on top of the plate, and a blanket covers both to ensure even pressure when pressing. The paper is pushed onto the ink creating an image.

The idea of halftone printing is attributed to William Fox Talbot in the late 1850’s. There were many different methods to produce the halftoning effect, and the earliest trials involved directly etching the images formed on Daguerreotype metal plates. However, the time and skill required to perform such an etching, the inability to print images next to type, and the quick to wear out fragile plates, meant that the process was impractical for commercial publishing. The turning point came in 1881 when Frederic Ives patented a commercial halftone method in the United States.

Frederic Eugene Ives inserting a Kromogram into his Kromskop, circa 1899

 Frederic Eugene Ives

Ives wanted to find a process to convert photographs into small black or white lines or dots, and to use a printing block which could be used alongside text blocks in an ordinary printing press. The lines and dots could vary in size, but had to be small enough that from a normal viewing distance they blended together giving the illusion of shades.

The “Ives’ process” was gradually refined and photographs were rephotographed directly onto a metal plate coated with photoresist (a light sensitive material). The popularity of the process spread quickly and by the 1890’s it was used widely replacing earlier hand-engraved wood block and steel plate illustrations. This was the standard process for photographically illustrating books for the next eighty years.

A 3D rendering and colour scale display of the Fairbairn printing block shows that the depth of the stippling is about 86 microns.

3D visualiation of the halftone printing block. The dots are typically 86 microns in depth

Electrolytic copper layer

Type metal (or hot metal) is the metal alloy used in typefounding and hot metal typesetting. It consists of mostly lead with some tin and antimony. The type metal in this block has a copper electrolytic layer and is screwed onto a wooden block. The electrolytic layer is very thin and can be scratched easily revealing the type metal underneath.

Electrolytic layer scratches at 100x magnification

Image of losses of electrolytic layer at 200x magnification

 The copper electrolytic layer is easily scratched. Areas of damage where the copper electrolytic layer has been lost reveal the type metal (lead with some tin and antimony) underneath

The printing block is backed with a paper sheet and ink stains pervade both the backing sheet and the wood block giving a wonderful insight into the history of the item. We often forget that collectibles which today gather dust were heavily used at some point in their lives.

Profile of the printing block under the microscope lens showing printer’s ink residue and paper backing under magnification

Image taken of the profile of the block at 50x magnification

Halftones are considered to be what is known as a photomechanical or process print. Other photomechanical prints include line blocks, photogravures, photolithographs and collotypes. Digital halftoning replaced photographic halftoning in the 1970’s and the theory forms the basis for how the CMYK colour space works using dots of cyan, magenta, yellow and black. You can read more about CMYK in a previous @BL_CollCare post: What the CMYK? Colour spaces and printing.

The printing block in this article depicts Steve Fairbairn (1862-1938) and was kindly loaned by Pauline Churcher of Thames Rowing Club. The Head of the River Race is a 6.8 km processional rowing race held on the Thames each year from Chiswick to Putney with the tide. It was founded in 1926 by Steve Fairbairn who dedicated his life to the sport by both competing and coaching to high levels. The race began with 23 entries and today boats well over 400 crews. The coveted prize is a bronze cast bust of Steve Fairbairn - which is the image observed in the printing block.

Christina Duffy (@DuffyChristina), Imaging Scientist

When a rolled rectangular panel painting arrived in the studio, it resembled a caterpillar in more ways than one. It was long, brown, spotty and unattractive! One could only glimpse, peering round the edges, the beauty it would become!

Rolled painting revealing far left hand side of image. Depicting trees and a person in the top left corner

Surface damage on the back of the rolled painting

 The object before conservation

The painting dated 1850-1880 was acquired at an auction in 2007. When it was first assessed for conservation, it was tightly rolled, and the assessment was based on viewing the exterior of the roll only. However, the curator, Jana Igunma, told us that the painting had been pulled open once for viewing at the auction.

Looking round the edges it was possible to see that the painting was executed in water based paints on a thick layer of gesso and backed with linen. The panel was additionally made stiff by another layer of very discoloured board. It looked as if, at some point of its life, it had been forcibly pulled from that board and the painting, in self defence, curled up into a tight tube! The painting was now waiting to be opened again, but the stiff and acidic ‘cocoon’ had to go first if the butterfly was to be born!

We proceeded with caution, making sure that the cracked paint layers were not damaged in the process.

Close up image showing green tweezers removing the brown backing

The back of the scroll being pressed with a glass weight, blotter and bondina after the stiff backing has been removed

 The backing was gradually removed and then pressed using glass weights

Extensive trials and tests were carried out to determine the most efficient method for removing the backing; only some of the paper could be removed dry with the rest firmly attached. Alcohol and water solution proved most efficient in allowing the gradual removal of the backing without too much penetration of the paint layers, protected additionally by the thick layer of gesso. The paint layers and moisture penetration were checked regularly to see whether there was any indication that the procedure had a detrimental effect on the paint.

The removal of the backing, coupled with gentle pressure applied from the verso, relaxed the painting enough to allow it to be opened gradually.

The back of the unrolled painting, which is being lightly pressed with glass weights to flatten the painting

 Glass weights were used to press and flatten the painting

When the backing board was completely removed, the paint layers were reassessed. Although the surfaced was covered in tiny cracks resembling a spider web, most of the pigments appeared in good condition; the exception being the white pigment applied on gold. A few small chunky flakes were re-attached using isinglass (fish based adhesive) applied by brush. The most ‘dramatic’ of those flakes involved an eye, as illustrated below! The white on gold areas were additionally consolidated by applying another adhesive as fine mist over the areas.

Close up of the deity before treatment showing losses to the painting

Close up of the deity after treatment with the eye back in place

 Left: The deity on the left with no eye, and right: the eye re-attached in place

After conservation, the object was hinged onto a lightweight board and boxed. This completed the ‘chrysalis-like’ transformation of the object from a roll to a beautiful painting that can now be fully appreciated!

Image of the painting after treatment, flattened it depicts a vibrant scene

 The painting after conservation

The rectangular painted linen panel depicts scenes from the life of Buddha, which is a very rare subject in Thai manuscript or miniature painting. The painting style is clearly Rattanakosin (1782 - present) . Similar scenes from the life of the Buddha are depicted on mural paintings in Thai Buddhist temples built during the 19th century. The fact that this painting was produced in order to be framed and mounted on a wall indicates that it was possibly done to cater for Western tastes, and might even have been a copy of a mural.

A more thorough study of the painting now that it can be fully accessed may reveal more than we know about it at present.

Iwona Jurkiewicz

I would like to thank Cordelia Rogerson for providing the initial assessment of the painting, Jana Igunma for giving us the information about the object and painting conservators: Nicola Costaras, Audrey Marko, Beatrice Villemin and Odile Hubert, who with their expertise, time and encouragement helped me bring this project to a successful conclusion.

This is the second in a series of blog posts discussing the challenges of caring for the national newspaper collection - how we’ve worked to preserve it and keep it accessible in the past and how we are going to do so in the future.

The national newspaper collection is on the move. Its current home at Colindale is no longer fit for purpose – either as a repository able to offer long term sustainability to the collection; or as a facility for readers to experience the modern, dynamic newspaper and news service that we want to offer. This recent BBC News report paints a vivid picture.

We know the collection is vulnerable, and if we don’t act now to move it into better conditions, we risk more of it falling into such bad condition that we will be unable to issue it without increased damage or loss, if at all.

Our survey says…

In 2001, as part of a three year project to survey all of the Library’s collections on all of its sites, we surveyed the newspaper collections at Colindale using the PAS (Preservation Needs Assessment Survey) methodology. The results showed that the newspaper collection is the most vulnerable of all of the Library’s collections and gave us a statistically sound picture of the state of this national collection. Our results showed that 34% of the collection at Colindale was unstable – 19.4% in poor condition, 14.6% unusable.

We know that improved storage is the best way of preserving the whole collection for the long term, and our new Newspaper Storage Building (NSB) is undergoing its final testing as I type.

However, this is just the latest – and most ambitious – effort to strike a balance between the long-term preservation needs of the collection and our duty to make it available to users.

The ties that bind

Wooden sign directing to the bindery workshop on the 3rd floor in gold lettering

When reader facilities were added to the original Colindale repository in 1932, a bindery was also created on the 3rd floor. Here, new legal deposit intake was bound, and older papers were conserved – pulled down, de-acidified, repaired and re-sewn and re-bound. Treatment and binding styles varied depending on the age, type and size of newspaper - machine sewn; hand-sewn on tapes or cords, buckram and leather, half and quarter; finished in foils, mostly, but occasionally gold leaf.

As the conservation and binding of newspapers proved to be less and less cost and time effective over the years, benefiting only a small part of a vast collection, the bindery was closed in 2001. However, because of the work that was done, there are many thousands of volumes in perfectly good condition today that otherwise wouldn’t be.

Below, the bindery at Colindale in full production in the 1980s.

Image showing the binders working in the Colindale in the 1980s

 Newspapers ready for sewing, by machine and by hand

Image shows workers in the bindery preparing newspapers for sewing

 Forwarding and finishing

Lights! Camera! Microfilm!

We know that not everyone is a massive fan of microfilm. From a user point of view it has few of the advantages of digital and it’s not the real thing. But for the long term preservation of content it has proved its worth and without the large-scale microfilming programmes undertaken in the 1970s and onwards, a significant portion of our content would simply be unavailable today in any form.

A worker in Colindale microfilming a large volume. The book is on a stand and there are lights above

A worker in Colindale microfilming a newspaper

 Microfilming at Colindale began in the 1950s. In 1971 a dedicated microfilm unit was completed. At its height the unit operated 20 cameras and the BL produced (internally and externally) approximately 13 million frames of newspaper content annually

For we are living in a digital world, and I am a digital girl...(sorry, Madonna)

We still copy newspapers today, to increase access to content and to preserve the originals, but the format tends to be digital rather than microfilm. For instance the Library is working in partnership with DC Thompson Family History to digitise 40 million pages of 19th and early 20th century newspapers and make them available on the British Newspaper Archive website. Interestingly, where we can’t scan the original newspapers, the microfilm we created over the last 50 years is proving an invaluable alternative scanning source.

“What are you able to build with your blocks? Castles and palaces, temples and docks.” (from Block City by Robert Louis Stevenson)

Image of new storage building, the building is a mixture of greys and blues, it has a yellow door and railings along the front of the building

 The new storage building, with the main void at the back and the support building in front

Well, what we’ve been able to build with our blocks is a brand new storage facility for the national newspaper collection at Boston Spa, known lovingly as NSB – Newspaper Storage Building (we love to tell it like it is!). This state-of-the-art building will secure the long term future of the collection. In a complete (improved) reversal of storage fortune for the collection, it will be stored in the dark which will protect it from the damaging light levels that were unable to be controlled at Colindale.

The temperature will be 14⁰C and relative humidity 55%, a vast improvement on what was able to be achieved at Colindale. More importantly, it will be maintained at a steady level which overall will provide an environment for the collection that will slow down the rate of deterioration. Crucially, the oxygen level is purposely low at 14-15%, eliminating the risk of fire (ignition is impossible). The ingest and retrieval of newspapers is automated, which means in turn that the storage can be high density.

Lying down on the job

Not us – the collection! If you read our first post, you’ll know that the collection varies in size enormously, from volumes no bigger than a pocket diary to volumes weighing nearly 20 kg. Storing these large and heavy volumes vertically is causing physical damage, particularly where the boards are no longer attached and providing support, so in the new building the collection will be stored horizontally in stacks which will ease the pressure on the bindings and stabilise the text block. A ‘stack’ consists of a bottom board, a stack of volumes, and a top board. The boards and the stack are secured by straps. The stacks are stored on huge carrier trays in the storage racking, each holding various permutation of stack sizes.

It all stacks up

We’ve set a maximum stack height of 400 mm for each stack. Volumes will be grouped together by condition and stacked by size, with bound volumes being alternated spine to foredge to provide a stable stack with an even weight distribution. In order to do this, we’ve undertaken a massive data gathering exercise, determining the size of every item in the collection and assigning a condition rating of good, poor, or unusable.

Size

Graph showing the seven sizes or footprints, relating to the board sizes on which items will be stacked

The collection was divided into seven sizes or footprints, relating to the board sizes on which items will be stacked. Footprint 1 is any volume up to 380 mm (h) x 310 mm (w), while footprint 7 caters for volumes between 820-1012 mm (h) x 680-770 mm (w) – we have several hundred of these.

It’s a wrap

Knowing the condition of each item in the collection is important if we are to direct our resources appropriately and effectively. For this project, it was even more crucial because of the handling and transport logistics involved in moving from one building to the other. To protect items that are particularly vulnerable, we are shrink-wrapping those in poor and unusable condition.

A pile of shrink-wrapped volumes being tested for stability

 A stack of three shrink-wrapped volumes, being tested for stability

Three images showing the construction of the building from the beginning and throughout the building process

The installation of a giant crane inside the building

 One of the giant cranes is lifted into place. These will run up and down each aisle delivering carrier trays through a sealed air lock to the work stations in the support building

Another image of the giant crane inside the building, this image also has several site workers in it which highlights the vast size of the crane and space

Image of the light grey and yellow work stations with fencing behind them

 The workstations in the support building

Two workers building stacks inside the test facility. With many large half leather bindings with brown spines in two piles

 Stacks being built in a dedicated test facility

It’s no small undertaking to move such a large and vulnerable collection half way up the country, so in our third post on this topic we’ll spend some time with Moves Manager Sarah Jane Newbery to find out what the challenges are – and how it’s all progressing.

For more information on the newspaper moves see: www.bl.uk/newspaper-moves and follow us @BL_CollCare.

Sandy Ryan

Conservator Ann Tomalak tells us about the new mobile conservation workstation being trialled at the British Library.

Because we are a library, our books get handled and read. Inevitably, a small number get damaged, either by accident or because the materials degrade as they get older, and fall apart. In order to get items with minor damage back into use as quickly as possible, we have a Running Repairs programme for work that will only take a few hours.

A pamphlet in urgent need of repair

Traditionally, Running Repairs have been done in the conservation studios alongside major conservation projects. Items needing repair are identified by curators, library assistants or readers and join a never-ending list, from where they are delivered in small batches to the Centre for Conservation every few weeks. The paperwork takes time. Every item has to be ordered individually, and security tracked. When the repair is finished, the conservator records the time spent on it, writes a report and attaches photographs. Then the process is reversed to get the item back to store.

The mobile workstation and its contents

Recently, we have been trialling a new method to get running repairs done more quickly, without compromising the quality of the conservation work. A mobile workstation has been kitted out with basic tools and lots of repair materials, so that we can take the conservator to the collection. The workstation is “parked” for a week or two in the collection areas – either in the storage pen or nearby, in curatorial offices. Colleagues are notified and soon come along, clutching damaged items. The conservator takes a quick look and discusses the options. Most running repairs can be done at the trolley, though a few items which need specialised equipment or advanced techniques must still be sent to the Centre for Conservation. A further few need extensive conservation and will be set aside for a full assessment.

A detached board and spine fragments. This routine repair can be done quickly, using only basic tools and materials

Taking the conservator to the collection means that we avoid the tedious ordering, tracking and delivery system. We have also greatly simplified the treatment record, simply noting the shelf-mark, work done, materials used and any other essential information, with a link to photographs. Since the conservator often works on several items at a time (for example, allowing one repair to dry while preparing another), the overall time spent on the visit is averaged over the number of items treated.

Conservation in progress at the workstation

Considering that a simple paper tear only takes 15 minutes to repair and a loose leaf can be reattached in well under an hour, the paperwork often took far longer than the conservation treatment. We estimate we are saving 30 minutes on ordering and delivery, 15 minutes on security administration and 30 minutes on the treatment report. This time can now be used for more running repairs, meaning items can be returned to use much more quickly.

A detached seal can easily be lost, so this is a priority repair

The curators are delighted. Treatments are completed to the same high standard, but precious books need never leave their sight and are returned to them quickly – often within hours. They can discuss the work with the conservator and talk through options. By watching the conservator at work, they also get a better understanding of what can be done as a running repair and what needs full conservation.

Folded material bound into a book is doubly vulnerable – the attachment point can tear from incautious opening and the folds eventually split

All in all, everybody benefits from the mobile workstation; not least our Readers who find damaged collection items return to use more quickly.

Ann Tomalak

Planning a digitisation project can be a lengthy process with consideration required for strategic alignment, funding models, workflow, and metadata – all of which should be led by a clear definition of the overall purpose of the digitisation project. What must also be considered are the practical aspects of digitisation bearing in mind the condition and format of items, and identifying what needs to be done to items to make them camera ready.

There are potential risks from digitisation as books become objects when being copied, and therefore may not be handled, positioned or viewed in the conventional way. This increased handling can accelerate the normal process of wear and tear. In order to minimise these risks the items should be checked over before appearing in the imaging studio. These checks are run by our Preventive Conservation team who make initial condition assessments of items to be digitised; recommend any treatments to stabilise or repair items; and advise on handling and transport, camera equipment, lighting and cradles. We are Collection Care after all!

The outcome of pre-digitisation checks fall broadly under five headings which will be covered in this post, and we’ll share some examples of what to look out for.

1. Items that can be digitised in their current state

Good condition, flat, loose leaf items, and bound items where all the content can be seen easily, and that open well, can be digitised.

Items in good condition which open well can be digitised easily. Depending on size limits these items may be suitable for scanning

For folded inserts, digitisation is best facilitated through use of a book rest to support the main volume allowing the insert to lie flat. A support can be arranged underneath to provide a flat base for large foldouts. Take note of the format and size of folded inserts as large items may be too big for many scanners, and may need to be photographed instead.

The value of a good measuring tape cannot be underestimated! This bound book (left) is 260 x 210 mm, but the insert extends to 770 x 500 mm. In guard books (right), the insert may be smaller than the volume in which case a sheet of paper can be placed behind

Guard-books which contain miscellaneous single documents or groups of documents usually open well, and if items are in a good condition then they can be photographed or scanned. If inserts are smaller than the volume then a backing sheet will need to be placed underneath to hide items behind. Size and positioning can vary through the volume so items may have to be repositioned under the camera/scanner. Items with wax or shellac applied seals and vulnerable manuscript items should not be scanned under glass as this can cause damage or make existing damage worse.

Some items may appear to be badly damaged but may still be imaged safely. For example if an item has a broken binding where the boards are off and the sewing has failed, it can be treated like single leaves. If the boards are completely off, but the sewing and text block are still intact then it acts like a bound volume.

2. Items that may need some preparation

It may be possible to photograph rolled items without preparation. If the roll is particularly long then it may need to be photographed in sections with weights positioned to prevent the item rolling up between shots. Where rolled items are distorted and do not lie flat easily (even using weights), they may need some relaxing and pressing first. Bound items which have been rolled need to be relaxed and flattened for digitisation.

 Some rolled items can be digitised using weights (left), while others (right) may need some care before imaging

Folded items may need to be photographed separately and in sections as they can be much bigger than they first appear. It is important to know how much space is needed as a different location and set up may be needed to capture large items.

Items may be larger than they seem! This fold out map requires a large working space which imaging studios may not be capable of accommodating

Past stationary remedies such as pins, treasury tags, fasteners and adhesive tapes can damage paper. Rusting induced by a high humidity environment can stain underlying paper. Preparation time may be needed to remove pins, fasteners and threads. Tape removal can be more time consuming involving the work of a conservator. You can read more about tape removal in our Conservation Revealed blog post.

Bad storage and poor housing can cause problems making items difficult to handle and lay flat. These items may need to be prepared for digitisation by relaxing and flattening – this is a relatively simple job, however if there is a lot of material it can be time consuming.

Poor storage (left) and broken threads (right) can make items difficult to handle

In all of these cases, time has to be factored in for preparation of material.

3. Items that may need minor conservation work

Ideally dirty items should be surface cleaned to remove loose dust and dirt before imaging. Ingrained surface dirt is very difficult to remove so the item may have to be imaged as it is, or even excluded if the condition is detrimental to the project. It’s worth keeping in mind that the appearance may be part of the ‘story’ of the material.

Damaged covers (left), and torn pages (right) can be digitised after minimal localised conservation

Outside leaves may be more badly damaged than text blocks, and it may be the case that a few leaves in a text block are torn. These items may be digitised after minimal localised conservation. It may also be possible to place torn loose items into Melinex sleeves to hold flat as an alternative to other preparation/conservation.

Mouldy items can cause damage, losses, staining and weakness to paper. For health and safety reasons, this material needs to be checked by a conservator. It may need to be dried if active and should be cleaned to remove mould spores before being safe to handle.

4. Items that may need more extensive conservation work

Extensive tears and detached sections may need to be repaired. All folds are vulnerable to tearing. If bindings have to be pulled for rebinding, digitisation can take place beforehand – single pages may be easier to handle.

Already damaged material such as this torn foldout is vulnerable to further damage. Check if any items are scheduled for conservation work which may make digitisation easier

5. Items needing handling input as an alternative to conservation

Some inks such as iron gall ink can cause degradation of otherwise good quality paper. Where the damage is extensive and the paper is very brittle, it may be quicker to image with a conservator handling and setting up the items with the photographer.

Having a conservator in the imaging studio to handle ink burn through (left) or loose leaves (right) may be quicker and less expensive than arranging full conservation work

Some bound items may be in very good condition but have restricted openings. Tightly bound volumes often result in text disappearing into the gutter of the book. These types of items can be difficult to digitise and adaptations to book cradles using straps and weights may be needed to enable them to be handled. Most books should not be opened wider than 120° unless they do so naturally. Openings throughout the volume should be checked for opening characteristics. Generally books should be positioned so that supports hold the item open at a safe angle for that item. Opening characteristics can change as a book is worked through, and volumes may need to be adjusted regularly to ensure the item is sitting correctly. Angled book rests can be placed on one side to allow the page being imaged to lie flat.

Opening characteristics of books: Rigid tight back in conventional reading position (top left), hollow backed book in conventional reading position (top right), tight paperback 90° opening (bottom left), tight binding opens to barely 90° (bottom right)

You may decide that highly valuable items should be accompanied and/or handled and set up by a conservator or curator. This time and cost will need to be factored in to the project.

Decisions about preparation sometimes depend on the purpose of the digitisation project, e.g. to publicise the collection or to provide a study source. This may affect the level of preparation needed for digitisation, i.e. whether or not to relax and flatten items. Digital copies may raise awareness of physical items and increase demand to see the original – so decisions about future access need to be addressed. Planning for a digitisation project is vital to ensure the success of your project, with the emphasis on balancing the benefits of producing a digital copy against the risk of damage during the imaging process.

Christina Duffy (@DuffyChristina)
Imaging Scientist

An event on gold finishing was held in the British Library Conservation Centre to celebrate a recent antiquarian acquisition of a rare example of an 18th century book cover lavishly decorated with gold. Gold finishing, or gold tooling, is the decorative process of covering the spine and/or covers of a book with gold leaf designs. Visitors including many VIPS such as the Dutch Ambassador got a unique chance to view the acquisition and to watch book conservator and gold finisher Doug Mitchell demonstrate the technique in person.

Book conservator Doug Mitchell prepares to demonstrate gold finishing.

The 18th century acquisition is often referred to as the Binder’s Sample. It is thought that the good condition of the tooling, the high quality leather, and the use of 33 different tools are evidence that the cover was produced to showcase the binder’s skill when seeking new clients. It is a sample book cover (Folio 362 x 249 mm) of limp speckled calf dating to about 1730 and originated in Utrecht or Amsterdam.

Gold finishing designs are impressed onto leather covers using a variety of tools including heated brass letters held in type holders, and decorative tools such as pallets, fillets and rolls. In the Binder’s Sample three rectangular outer frames showcase five different rolling tools. Most distinctive are the hunting roll; depicting a hunting lodge unlike the more traditional hunting roll, and the musician roll; showing harpist, vocalist, triangle player, viol player and organist separated by a stag, bird, lion, hound, gryphon and a crow eating grapes.

The Binder’s Sample, Utrecht or Amsterdam approximately 1730. 33 different tools were used to create this extravagant cover.

The musician roll used on the Binder’s Sample was a particularly fine roll and was a reverse cutting of a roll belonging to the Amsterdam Double Drawer Handle Bindery. This particular roll was used from the mid-1720s to 1730s on presentation copies of books for the luxury market. Below are some examples of the rolling tools used at the British Library.

Rolling tools were used for border designs.

This rolling tool depicts interlacing spirals which create a flowing pattern along the binding when applied.

The central field of the Binder’s Sample showcases 27 different tools. In the centre is a coat of arms depicting a man in a loin cloth with the scales of justice in his right hand and a bird of prey in the left hand. Corner pieces include blooms, angels (one with a quill pen), stars, foliage, scallop shells, pomegranates and vases.

Variety of tools used to produce different designs.

For the demonstration Doug used a goatskin leather dummy book held in a finishing press on the workbench. The leather was size washed with a wheat starch paste and an adhesive made of egg whites, called glair, was applied to the leather where the gold leaf was to be placed. The surface is then smeared with Vaseline. A sheet of 23.5 carat gold leaf was cut into a suitable size for the design and placed onto the glaired area on the spine of the volume. Gold leaf comes in two thicknesses; single and double with the latter used primarily by British Library conservators.

Doug Mitchell carefully cuts a sheet of gold leaf using a knife.

The gold is placed on top of the greased area of the volume.

A heated tool is then used to press the gold leaf permanently into the leather using a combination of heat, dwell and pressure, leaving an impression dictated by the shape of the tool. The remaining gold leaf is rubbed away revealing an intricate design.

The heated tool is pressed perpendicularly onto the gold leaf which is on the spine of the volume.

Doug also demonstrated tooling onto cloth using a Type holder tool. In this case the word LIBRARY (my favourite word!) was pressed onto real gold foil.

Larger tools can be used to apply text to the spine and is applied in the same way as smaller designs.

The gold doesn’t tarnish and has an affinity to the leather such that it is very difficult to remove.

When the excess gold is removed the spine is left beautifully decorated.

Doug had previously prepared a British Library version of the Binder’s Sample, copying the format to display just some of the extensive collection of finishing tools here at the conservation center, shown to the right in the image below, which was on view for visitors to compare to the original.

The Binder’s Sample is examined by Nicholas Pickwoad (left) and was displayed next to the replica (right)

A sheet of Vivak was placed behind the Binder’s Sample by our conservators to allow readers to view the reverse side, which would be obscured if mounted on opaque material.

The Binder’s Sample as viewed from behind showing the Vivak reverse mount.

Although the popularity of gold finishing has declined in recent years, tooling is an important part of any conservator’s skillset. An exhibit showing the vast  array of tools available is on display in the Conservation Centre.

A display of bookbinding tools inside the Conservation Centre showing an example of the huge range of equipment available.

Visitors were shown a display and given a demonstration of tools used in conservation.

Gold leaf is nearly always used for this type of decoration due to its lasting qualities. Other varieties include white gold leaf which gives a silver appearance, or pigment foils (red, green blue etc.) which can be used on cloth and paper bindings. The British Library uses gold finishing on all its leather bound books. Generally gold finishing is done to re-produce the design that was on the original, but some of our collections such as Sloane, Egerton, Harley and Cotton manuscripts have an existing format. When no reference is available designs are based on the year of the book by choosing the tools that were appropriate for that time period.

The skill of gold finishing is very difficult to master and requires precision, patience and perseverance!

Christina Duffy (@DuffyChristina)
Imaging Scientist

Further Reading:

For more about the musician roll see Storm van Leeuwen’s pamphlet Dutch
Decorated Bookbinding in the Eighteenth Century r III in C55, C 61, C 66 & C 72
-3 (1727 – 38) and I pp 234, 237, 239 & 252-3

Bookbindings in the British Library

Database of Bookbindings

We recently posted about parchment and how our conservators treat parchment collection items, but what is the difference between leather and parchment?

Parchment and leather are both made from animal pelts, but parchment does not undergo tanning as leather does. The process of tanning traditionally used tannin which is an acidic chemical compound making material less prone to decomposition - including molting and holding odours. Good leather is waterproof and more durable than parchment. These properties have led to leather being used for clothing, footwear, upholstery, armour, and as a writing material. Book bindings are sometimes covered with leather and display a grain pattern where follicles are observed. Follicles are mammalian skin organs that produce hair, and variations in their distribution and frequency can help researchers determine the species of animal used. Variations in texture, colour, and thickness of leather also offer clues.

Due to the variety of material in our collections, we have samples of different animal leathers in our conservation studios. The most commonly used varieties of covering material for bindings in the British Isles were calfskin, sheepskin and goatskin. Here we go under the microscope to take a look at the follicle distribution of goat, kid, calf and sheep leather.

Calf

The most frequently used tanned skin for binding was calfskin. It is often found plain but sometimes a pattern effect is achieved by staining with paint or acid. Cow hair is fairly evenly distributed and serves to insulate the animal’s body.

Figure 1: Calf leather at 100x magnification.

Goat

Microscopy of goat leather shows two rows of follicles of different sizes indicative of a two-coated fleece. The larger follicle is known as the primary follicle and produces the goat’s guard hair which is present all year round. The smaller follicles are called secondary follicles and produce an undercoat which grows more during the colder winter months. The undercoat is made up of soft, downy hair and is the hair used for fine materials such as cashmere when taken from Cashmere goats.

Figure 2: Goat leather at 100x magnification. Two rows of follicles are observed; the smaller secondary follicles produce down while the larger primary follicles produce guard hair.


Kid

Young goats show a similar skin structure to the adult goat, but follicles are not as apparent in kid hides. Goat and kid leather was used for the best quality work being known for its well-grained, shiny and hard-wearing surface.

Figure 3: Kid leather at 100x magnification.


Sheep

Sheepskin has narrow follicles which produce crimped wool fibres. Crimped fibres distinguish wool from the straighter fibres found in hair or fur. It is this crimped profile which makes sheep’s wool a great insulator by trapping air and becoming bulky. Wool is also elastic and grows in clumps known as “staples” as observed below. Fine wool such as Merino has more crimps per inch than other wools.

Figure 4: Sheep leather at 100x magnification. Clusters of follicles called staples are observed.


Figure 5: A comparison of parchment follicle patterns from kid, goat, sheep and calf at 200x magnification.

Bookbinding leather

Tanned leather is difficult to shape into a flat and smooth surface free from wrinkles. It therefore quickly fell out of favour as a writing surface, but grew in popularity as a covering material for bookbinding. Leather is sometimes decorated with a worked design such as that seen on the St Cuthbert Gospel, which has a late 7th century binding. The leather cover was stained in crimson on the outer surface and moulded over a designed board while still damp. Tooling and the addition of other pigments enhanced the decoration.

    Figure 6: Leather as a covering material on the front of the St Cuthbert Gospel.

Figure 7: 50x magnification microscopy image of the leather on the back of the St Cuthbert Gospel; can you guess which animal this leather comes from?

Red rot

Some animal breeders use the density of hair follicles in their promotional material as a means of promoting leather quality, but follicle density is related to surface area and is not necessarily indicative of an animal’s health. It is not surprising that the health of the animal is reflected in the quality of the leather produced. Agricultural improvements in the late 18th century led to larger animals with poorer quality skins. This combined with mechanised production methods and the use of condensed vegetable tannins contributed to leather which later suffered from red rot.

In the red rot process hydrogen peroxide is formed from the conversion of sulphur dioxide to sulphuric acid. Acid deterioration causes fine cracking and the formation of a red/brown powdery surface. The structural integrity is compromised and loss occurs. The powder can also transfer to reader’s hands and adjacent volumes.

Figure 8: Examples of red rot on leather bindings. Red rot can cause boards to completely delaminate.

Leather binding, although tougher than parchment, still has many of the same preservation needs and should be kept free from fluctuations in relative humidity, light exposure, temperature fluctuations, dust build up and pest attack.

Christina Duffy (@DuffyChristina)

Imaging Scientist

Did you know that ownership stamps are applied to items accepted into our collections?

Ownership marking is the application of the official British Library ownership stamp. The ownership stamp is used for security purposes and in tracing the provenance of the collections. Examination of the book itself is quite often the best place to start when trying to establish the history of an antiquarian book, and library stamps (acquisition stamps and book stamps) might indicate how and when it was acquired. Ownership of an item was routinely shown by the British Museum, and subsequently the British Library, by using inked stamps. These stamps give a fairly precise date of receipt for the volume leading to entries in acquisitions registers or invoices. A series of stamps was compiled by René Payne in 2007 from which many of the examples in this post have been taken.

Our Library stamps are generally divided into four types according to when they were in use ranging from 1753 up to the present day.

TYPE 1: 1753–1836

From 1753 to around 1836 stamps containing the words MVSEVM BRITANNICVM or MUSEUM BRITANNICUM were in use. The shape and arrangement of the stamp varied over the years and sometimes contained the initials of the previous owner.

A library stamp specially cut to include the initials of the previous owner, Revd C.M. Cacherode.

Stamps were often placed near areas of interest such as this inscription on IB 49437

TYPE 2: 1837–1929

Type 2 stamps covered the period 1837-1929 and were oval in shape. They contained the royal arms flanked by a lion and unicorn beside the words BRITISH MUSEUM. Between 1837 and 1849 stamps were annotated with a pencil to indicate the exact date of entry in the acquisitions records. They occur in the shape of a diamond giving the date of acquisition and a reference line in the Acquisitions Register. In the example shown below from the Help for Researchers webpage, moving clockwise from the left the numbers represent  the month of acquisition (10 = October), the year of acquisition (44 = 1844), the day of acquisition (18 = 18th), and the entry line in the Acquisitions Register for that day (line 144).

Annotated library stamp in volume at shelfmark 1462.h.4 [Vitterhets Arbeten by G.F. Creutz and G.F. Gyllenborg (1812)].

Oval stamp issued on 1 September 1905

As seen in the journal The Lancet on 20 February 1915.

British Museum stamp dating 25 October 1920 showing a variation of the crown in an oval

 Figure 4: Oval stamps containing the royal arms flanked by a lion and unicorn with the words BRITISH MUSEUM; used 1837-1929. An abbreviated date of acquisition may be added, either with another inked stamp or in pencil. Note the variation in design. After 1929, the stamp was changed to Figure 5 (left)

TYPE 3: 1929–1973

Type 3 stamps were used from 1929 to 1973. They consist of round stamps containing the royal arms but no lion or unicorn, and the words BRITISH MUSEUM. Earlier stamps included an abbreviated date of acquisition e.g. in Figure 5 (left) the date is 15 February 1944.

Round British Museum stamp with abbreviated date of 15 February 1944.

British Museum hand stamp used in small books and delicate or rare items

British Museum stamp below an illumination on f.46v of Add MS 36928.

British Museum stamp below writing on Cotton Tiberius B8

TYPE 4: 1973–present day

Type 4 stamps reflect the time when items were stamped with the words BRITISH LIBRARY rather than BRITISH MUSEUM - a key turning point in the History of the British Library. The British Library Act was passed by Parliament in 1972 which brought the Library into operation from 1 July 1973.

India Office stamp dated 3 August 1955.

Document Supply Centre's official publication stamp dated 18 June 1980. It has been suggested that it differs from the round stamp because of where the item was received i.e. received in Yorkshire rather than London

The words BRITISH MUSEUM were replaced with BRITISH LIBRARY, but retained a similar style to earlier stamps

These round stamps have been applied to early printed books acquired since 1973.

 Figure 9: Left: Hand stamp for a delicate or rare item. Centre: Crown hand stamp for Asia, Pacific and Africa Collections material. Right: Hand stamp for antiquarian material

 Figure 10: Left: hand stamp for a delicate or rare item. Centre: Hand stamp for manuscripts. Right: India Office hand stamp for small 'claim material' items. Treated as BL collection

The stamp in Figure 11 shows the initials OIOC (Oriental and India Office Collections) which now reside within the Library's Asia, Pacific and Africa Collections.

 Figure 11: Left: Oval hand stamp for manuscripts with the words BRITISH LIBRARY. Centre: India Office hand stamp for non-small 'claim material' items. These items were treated as part of the British Library collection. Right: Library stamp from previous Oriental and India Office Collections. Use of this stamp ceased on 1 September 2005

Significance of the ink colour

Different colour ink was used for library stamps depending on the purpose. All inks have been tested to ensure they comply with conservation standards.

• Blue ink represents legal copyright deposit material of British, Irish or colonial origin including material from the Old Royal Library
• Red ink typically indicates a purchased item, but a square red stamp may indicate that a book was donated as part of the Edwards Bequest
• Black ink was used on a wide range of early acquisitions, including books from the library of Sir Hans Sloane; on purchases made in 1781–1798 and 1804-1813; and on copyright deposit materials received 1813–1816. It was re-introduced for much of the 20th century to indicate materials acquired through international exchange. Black ink was discontinued on 1 September 2005
• Green ink represents a donation made since 1944, or an exchange item
• Yellow/orange ink represents donations made between 1768–1944
• Brown ink represents a donation made before 1768

While library stamps are a useful aid in determining the history of a collection item, it has been noted that many items were stamped much later than their acquisition date and mistakes are known to have occurred. Library stamps should provide just one piece of a greater body of evidence for determining both the circumstance and date of acquisition. Clues may also be found on bindings, bookplates or inscriptions.

Ownership marking is carried out at St Pancras and Boston Spa in secure areas with restricted access. Our colleagues in the Operations Division are responsible for stamping any new material that comes into the library. A new system is being introduced very soon which we will cover in a future post. Thanks to Graeme Bentley, Goods Inward/Finishing Team Manager, for input on this topic.

Christina Duffy (@DuffyChristina)

Imaging Scientist
