As part of the Hebraic Manuscript Digitisation Project (HMDP), we are currently imaging 74 scrolls. These range in size from one smaller than a little finger to another a whopping 52.41m long – three times the length of the conservation studio. The tallest is nearly a metre with its rollers.

Esther scroll in decorative case (Add 11831)



We did a brief survey last year and realised some of the scrolls were very damaged, so we have spent another two months assessing each one individually. Even this was not a simple task. Many of the larger scrolls are also very heavy, so two conservators have worked together to make sure they were handled safely, using lots of weights as stops to prevent them rolling off work-surfaces. The parchment scrolls have been tightly rolled for a very long time and even looking at them has been a challenge, as they try hard to re-roll themselves unless held down securely.

Text was rewritten after surface delamination; plus insect damage and excreta (Or 4224)



What are they? As well as some fine large Torah scrolls on parchment, made for synagogue use, we also have a number written on leather. The most important of this group is the Kaifeng Torah, made in central China in the 17th century. Read more about it here.

There are also much smaller scrolls made for personal or family use. In particular, we have quite a few Esther scrolls, and some with the ritual texts for the Passover meal. Most copies of Hebraic scriptures are unadorned, to focus attention on the religious texts, but scrolls for family celebrations may have decorative margins or full coloured miniatures. The smallest scroll, adorned with silver, was almost certainly an amulet as the script is too tiny to be easily read.

 The smallest scroll. The finger appears huge in comparison to the tiny script. (Or 4670)

The survey showed that up to half of the scrolls needed some kind of conservation treatment. Many were quick tasks done during assessment (edge tears or broken sewing joining panels) to avoid having later to roll and re-roll the scroll yet again. However, a dozen of the scrolls needed a good deal of repair simply to get them through the digitisation processes safely, and were sent to the main conservation studio.

Sewing is too tight and the holes too close together. The leather surface is also crazed and inflexible in part. (Or 1462)



Many of the scrolls have integral rollers. We thought it safer not to repair these if broken, lest it give a false sense of security, though we never lift scrolls by the roller handles anyway, since so many are now frail. Even more fragile are the few scrolls that roll back into cases as the mechanisms now tend to stick. Thankfully, once digitised, these will be handled rarely.

Common damage: the sewing has broken and a tear has developed across the text. This must be repaired before imaging as handling will make it worse. (Or 4224)



The scrolls are made of rectangular panels of parchment or leather (often called membranes) joined end to end. We were surprised to find that the majority were linked only by long, crude running stitches of linen thread, but these joins had mostly remained intact. We understood this better when we found a pair of scrolls with joins of fine oversewing (possibly done by a seamstress, not a leather worker), where the thread had torn through the leather; the frequent holes essentially acting as a perforation strip.

Evidence of use is carefully preserved; here molten wax has dripped onto the scroll. (Or 1463)



A few of the scrolls have protective silk panels stitched to the verso at the outer end and we also found four mantles. Our textile conservator, Liz Rose, is cleaning and repairing these to make them safe to handle and image. They will be boxed separately and available for display in the future. As part of the project, many of the scrolls will also be rehoused in custom-made boxes.

An extremely damaged mantle; the silk lining is also split in many places (Or 13027)



Although our imaging technicians are well used to digitising oriental scrolls, as well as other rolled materials such as maps, we think this is the first time anyone has digitised such a large group of Hebraic scrolls. Conservators were involved early in the process of selecting suitable equipment. Although no Hebraic manuscript books have been scanned, we concluded that it would be safer and more efficient to scan some of the scrolls – though using the equipment unconventionally, without the glass sheet to flatten them. There was a full risk assessment before imaging began, and the imaging technicians received specialist handling training, including a requirement to work in pairs.

Marginal decoration of an Esther scroll (Or 1047)



Image printed on parchment and hand coloured. The printing block was probably generic, used to decorate many different texts, but is unusual for a Hebraic manuscript. (Or 13028)



Conservation’s role in the digitisation of the scrolls is now finished, but there is still several months’ work to be done on processing and stitching the images before everything is uploaded to our website. Meanwhile, you can view many of the books digitised during the project here: using “Hebrew” as the keyword.

Ann Tomalak, HMDP Phase 1 Project Conservator

We recently held a very successful public event sharing our conservation work in preparation for the British Library Magna Carta: Law, Liberty, Legacy exhibition. The exhibition marks 800 glorious years of Magna Carta since it was granted by King John of England in 1215. The conservation project involved removing six manuscripts from their frames and rehousing them for display. While they were out of their frames, the manuscripts were examined using various scientific techniques. High-resolution digital microscopy enabled incredible magnification of the iron gall ink and parchment which make up the charters. Here is a selection of the images captured of Cotton MS Augustus ii.106, one of the British Library’s two original Magna Carta manuscripts dating to 15 June 1215. Enjoy!

Imaging Scientist Dr Christina Duffy operating a digital microscope at the British Library.

Magna Carta 1215 (Cotton MS Augustus ii.106) – one of four surviving original 1215 copies.



Iron gall ink

Iron gall ink has been used since the middle-ages and is found on many of our most treasured collections including the Lindisfarne Gospels, Beowulf and Magna Carta. The main ingredients of iron gall ink include iron sulphate, tannins from oak galls and water. Overall the ink is in very good condition on this charter allowing us to appreciate the beauty in the detail of some of the initials.

Magna Carta 1215 detail.

Iron gall ink at 20 times magnification.

Iron gall ink at 30 times magnification.

Iron gall ink at 150 times magnification.

At high magnification we can see that some areas have experienced ink loss, but the Great Charter is still legible due to the remaining ink shadow left behind. Find out more about iron gall ink in a previous post here.

Magna Carta 1215 detail right side.

Ink loss at 30 times magnification.

Ink loss at 100 times magnification.

Ink loss at 200 times magnification.

Parchment

The parchment on which Magna Carta has been written is thought to be sheepskin. Parchment is an animal pelt which has had the hairs removed by liming or enzymatic action. It is then stretched and dried under tension creating a perfect writing surface with a thin opaque membrane. Below are some images showing damage to the  upper dermal layers of the parchment. Find out more about parchment here.

Magna Carta detail at the centre of the manuscript.

Damage at 30 times magnification.

Damage at 50 times magnification.

Damage at 150 times magnification.



You can find out more about this charter on the British Library Magna Carta resource page.

Christina Duffy (@DuffyChristina)

A CT scan of the St Cuthbert Gospel – the earliest intact European book dating to the early eight century - has been published in a ground-breaking new book launched this week: The St Cuthbert Gospel: Studies on the Insular Manuscript of the Gospel of John, edited by Claire Breay, Head of Ancient, Medieval and Early Modern Manuscripts at the British Library, and Bernard Meehan, Head of Research Collections and Keeper of Manuscripts at Trinity College, Dublin. Colleagues from Collection Care and Medieval Manuscripts took the pocket gospel to the Natural History Museum for CT analysis to understand the structure of the ancient gospel, which was found inside the coffin of St Cuthbert in 1104.

Figure 1: The British Library project team at the Natural History Museum. From left to right: Claire Breay, Flavio Marzo and Christina Duffy.

X-ray computed tomography (CT) is a non-destructive technique which creates 2-D cross-sectional images from 3-D structures. The St Cuthbert Gospel was scanned using a Metris X-Tek HMX ST 225 CT scanner with an operating voltage of 225 kV at the Natural History Museum.

To protect the gospel during scanning it was placed inside a custom-made phase box and then secured upright in a bespoke piece of polyethylene foam.

Figure 2:  The St Cuthbert Gospel was placed in a phase box which was secured in a piece of foam.

A facsimile of the gospel produced by Jim Bloxam and Kristine Rose was generously made available to the team during the CT scan. This enabled a direct comparison of materials known to be used in the facsimile with those unknown in the original St Cuthbert Gospel. Both volumes were placed inside the CT chamber on a precision rotation stage between an X-ray source and a detector.

Figure 3:  The two copies were placed side-by-side in the CT chamber.

As the volumes rotated on the stage through 360⁰ a conical beam of X-rays took digital projections in 0.5⁰ increments. The CT image pixels are displayed in terms of their relative radiodensity allowing us to scroll through the image slices revealing the materials underneath the leather binding.

Figure 4:  The results were poured over in the lab. From left to right; Christina Duffy, Claire Breay, Nicholas Pickwoad and Dan Sykes.

The results were initially examined by the British Library team and Professor Nicholas Pickwoad, whose chapter in the new publication draws on the CT scan results and discusses how the central motif on the binding appears to have been made using a clay-like material, rather than gesso or cord as previously thought.

Figure 5:  The St Cuthbert Gospel with raised plant-motif decoration examined under high magnification.

Figure 6: Analysis of the internal structure of the binding.

CT datasets contain vast amounts of information and samples can be visualised in many ways using various software tools. Drishti, which stands for vision or insight in Sanskrit, is an open source volume exploration and presentation tool. It allows volumetric data sets to be both explored and used for presentation of results.

Figure 7: A screen shot showing the St Cuthbert Gospel as visualised in Drishti.

CT scanning can provide tremendous amounts of information on the condition and construction of books and their bindings. This level of detail is unavailable through visual examination and can often lead to speculation. More information about the project can be found over on the Medieval Manuscripts blog. The new publication, The St Cuthbert Gospel: Studies on the Insular Manuscript of the Gospel of John, can be bought in the British Library shop or ordered online.

Christina Duffy (@DuffyChristina)



We’re delighted to announce that the conservation team behind the work done on the British Library collections in our latest exhibition Magna Carta: Law, Liberty, Legacy will be speaking at a public event on Friday 26 June 2015 18:30 - 20:30 to share their findings. Speaking on the night in the British Library Centre for Conservation will be Head of Conservation Cordelia Rogerson, conservator Gavin Moorhead, conservation scientist Paul Garside and imaging scientist Christina Duffy. Book your place here.

Join our project team of conservators and scientists on 26 June 2015.



The project spanned over three years in preparation for this year’s 800th anniversary of the 1215 Magna Carta and involved the reframing and scientific analysis of all of the Magna Carta charters held in our collections, including the two 1215 original versions.

Conservator Gavin Moorhead works on the 1215 Articles of the Barons (Additional MS 4838).



The team undertook an initial examination of the original frames to determine their structure and composition. At the event you’ll hear how probes were manually inserted into the frames to take samples of the air inside in order to determine what kind of micro-environment the charters were living in! The stability and compatibility of new materials, which would be used for mounting in the new frames, was ensured using infrared spectroscopy, pH tests, and lignin tests.

Mounting materials were tested before incorporation into the new frames. Join us to find out what the blue and red colours indicate.



With the frames removed the team had a rare opportunity to investigate the condition of the manuscripts using near-infrared spectroscopy and high resolution digital microscopy. Unpublished images of the ink and parchment at up to 200 times magnification will be shared with the audience.

What does 800-year-old ink look like at 200 times magnification?



You will also delve deep into the exciting world of multispectral imaging and see versions of the charters and their seals under ultraviolet and infrared light. The incredible results of the text recovery project on the damaged 1215 Canterbury Magna Carta, from which much of the ink was lost, will be shared.

Once our tests were complete it was time to rehouse the charters – you’ll hear from our conservator Gavin Moorhead about the challenges and decisions required to mount for display one of the most recognised manuscripts in the world which would feature as the dramatic finale to the exhibition.

The British Library's London Magna Carta at our exhibition, Magna Carta: Law, Liberty, Legacy.



Don’t miss out on this great event and book your place now! We look forward to meeting you!

Christina Duffy

The British Library Centre for Conservation recently hosted a professional course on Traditions of Papermaking in the Islamic World, organised by The Islamic Manuscript Association, in association with the Thesaurus Islamicus Foundation.

Add Or Ms 1699: A 19th c. watercolour from Kashmir shows the preparation of the pulp and papermaking. (Add Or Ms 1699)

The week began with a day of presentations covering every aspect of traditional Islamic hand papermaking, including early descriptions of the process, bibliographies, the characteristics of papers manufactured in different eras and different parts of the Islamic world, and the materials and tools used. We looked in some detail at the raw materials (mainly flax and hemp) and at the construction of the mould and screen on which the paper is formed. The process has continued in India into modern times, and we viewed films of traditional workers either squatting to work or standing in a pit.

Katharina Siedler shows the screen and supporting frame while Timothy Barrett explains the paper-making process

For the next three days the small group of participants made paper – though fortunately using smaller vats, so we could stand at a table. Two excellent instructors, Timothy Barrett (Director, University of Iowa Center for the Book) and Katharina Siedler (historian and papermaker, who has her own studio in Berlin) guided our efforts. The hemp and flax pulps had been prepared in a Hollander beater at the University of Iowa in both long and short fibred versions to give a sense of the characteristics of each. In addition, participant Jacques Brejoux (Moulin du Verger, France) brought linen pulp, prepared with a medieval-style stamper at his mill.

Tim makes the first sheet of paper

Islamic-style paper is made on a flexible screen made of grass, reeds or split bamboo held together with horsehair (think of a much finer version of a sushi rolling mat.) This is placed on a wooden frame, and removable side-pieces hold it flat. The mould is dipped into the vat of fibre suspended in water. It can then be floated, and gently moved to aid the formation of an even sheet of paper. The mould starts to drain as it is lifted from the vat. The side walls are removed and the screen lifted. The sheet of new paper can then be rolled onto a flat board (couching).

Katharina couches newly made paper.

British Library conservator Gavin Moorhead has a go

The next sheet is usually placed directly on top, though we interleaved with Reemay®, because of space and time limitations. When a good stack (post) has built up, another board is placed on top with weights to squeeze out more water. In warmer countries, the sheets are brushed out on walls to dry. We used a drying rack.

Jacques Brejoux presses the post while John Mumford (Thesaurus Islamicus Foundation) makes linen paper

By next day, our papers were ready to continue the processes of sizing them, allowing them to dry again, then flattening and burnishing them.

Tim separates the post of paper for drying

Everyone was able to take away some sheets of paper they had made themselves, plus good reference samples made by our instructors and, equally important, examples of common vat faults, so that we learn to recognise these when we find them in Islamic books.

Kristine Rose (Chester Beatty Library) sizes paper

Katharina makes burnishing look easy

On the final day a much larger group assembled for a symposium, summarising many of the topics and themes we had discussed in previous days and setting them in context. Librarians, conservators and historians introduced recent work and research in collections as diverse as the University of Michigan and the British Library. Those who had not been present the whole week stayed for a demonstration of paper-making at the end of the day.

The week was most enjoyable, but intensive and with serious purpose. Those of us who work with oriental collections now feel more confident to explain the marks or flaws in the paper that we encounter. We better understand the history of such items, and can use compatible materials and techniques if we have to treat them.

Ann Tomalak

Rob Sherman is the Interactive Fiction Writer-in-Residence for the current British Library exhibition Lines in the Ice. Part of his project involved inventing a new false history for a fictional explorer named Isaak Scinbank. With the help of our Conservation team, Rob created a journal which contained Scinbank's writings during his fictional voyage to the Arctic in 1852. Here Rob reflects on his time at the British Library.

Not many visitors to the British Library realise that the institution's political fulcrum lies hidden at the very rear of the St. Pancras complex, just past the staff restaurant and the windy, suntrap terrace.

This powerhouse is low-slung and decidedly shy for such an important building. Entering through the double glass doors at its front, a visitor is presented with a small museum to the work done inside.

During my time at the Library as writer-in-residence I was one of the few who could descend into the Conservation Centre, perhaps the most important cabinet in the Library's governance.

It is in this building, far away from the readers and the meeting rooms full of priceless paintings and the baize-carpeted hall of the executive suite that the real debate occurs. These are debates with the most incorrigible and old-fashioned of politicians; time.

Entering the private corridors of the Centre for the first time last year, I was accompanied by the closest to a party Whip that the conservators have; Dr. Cordelia Rogerson, the Centre's Head of Conservation and a specialist in plastics and textiles (two areas which I have barely any space or knowledge to consider here). She was giving me a tour to show me what it was that the conservators did. With relatively few exceptions, every unit of knowledge, discourse, history and artistry that the archives contain, every book and pamphlet and poster and tome, is slowly degrading. We have so abstracted these bricks upon which we build a culture that we easily forget what they are, materially; globsters, monsters, amalgams of different corpses.

Bookbinding has always used glue made from boiled bones, mashed trees and the skins of goats, whose unassuming little frames still dictate the standard sizing of our trade hardbacks. From the moment the book is bound it is dying a second death. The 'old book smell' is so fetishised that there are now colognes available which emulate it. Frankenstein and his monster are no more tortured than the vellum in which their first edition was published in 1818. Thinking this way, it is perhaps easier to imagine the Rooibos towers of the Library, so stately and sterile and civic from the surface, resting on a strata of almost-endless decay, a medicine cabinet full of slow-drying herbs, aging adhesives and mummified flesh.

The Library is a sarcophagus of knowledge.

From this organic perspective we may lend the conservators another role; that of the court embalmer, of Lenin's apparatchik, Mao's physician, keeping the cadavers moist and public for as long as possible so that those who come after can venerate them, divine what they need, and be able to say that they had been there, just like tourists.

Cordelia took me deeper into the building, past displays of golden tooling seals immortalised in cabinets like butterflies. We walked past labs full of test tubes and near-baptismal fonts of strange chemicals. Between the staff they possess every tool, modern and ancient, that they could need to help slow the inevitable degradation. They repair split spines, suture wounds in leather, and reconstruct text and gold leaf from almost nothing. I met one conservator, Maria, at her desk in the vast main room of the Centre, a cross between a surgery and a railway shed. She was attempting to resuscitate a Hebrew text from the 1400s which had, at some point in its ignominious existence, been submerged in water. Maria worked on that book with quiet, intricate confidence, and told me that she could save it, and it would be read again.

Her work, and the work of her colleagues, will never finish. With hundreds of millions of items in the archives in various states of decrepitude, some so advanced that they are at risk of being lost altogether, it is all the conservators can do to keep up. Work is allocated not in terms of books to save or projects to complete but in terms of hours spent; attempts are made, the best is done in some cases, and then they must move on to the next.

Cordelia introduced me to the two conservators with whom I would be working; Zoe and Royston both were as quiet and assured as Maria, with keenly open minds. Royston had worked at the Library for over 30 years and retired only a month or two ago, taking his incomparable, irreplaceable knowledge with him. It was after this meeting that I started to lay out exactly why somebody like me was there, and what it was that I wanted.

My project at the Library has been a petulant one, in which I essentially try to throw stones at the bedroom windows of history to get its attention. My artistic interests lie in how knowledge and rumour and rhetoric are transformed into unimpeachable historical record just by being written down, and what role the Library plays in storing and displaying such records for access. I was exploring these themes by attaching myself to the current exhibition at the Library, a diorama of Arctic exploration called Lines In The Ice, and inventing a new false history with all the attendant paraphernalia. I invented a polar explorer, and wrote songs about him, reams of false conjecture and essay, and drew maps of the journeys that he never took, parallel-parking him into the real stuff of the exhibition. It seems inevitable, then, that such an explorer needed a book of his own to legitimise him completely. I had come to the Conservation Centre to manufacture him one.

I wanted to make from scratch the journal that my explorer, Isaak Scinbank, would have written during his fictional voyage to the Arctic in 1852. My time at the Library has already impressed upon me the corporeality and authority of books, how very much the physicality of them affects how we interact with the information they contain. Because of this, I wanted the blank diary with which I was beginning to be as much a part of the story as Isaak's account written inside it. I described what I wanted to Zoe and Royston in the form of a 'biography' of the book, recounting not only its fictional creation but also its fictional journey through time to reach us in the present day. I designated it as a sort of fisherman's ledger, a present to Isaak from his father; clad in salmon-flesh leather, and embossed with the mark of its fictional publisher ('Thomas Whiflick, of Derby'). I described a large notch in its top edge, designed to be a rest for a gentleman's rods as he relaxed on the riverbank. More than this, I described the life of the book once its primary purpose was over; its existence since Scinbank had returned from the Arctic and died, passing through the hands of various collectors and dealers. I told of the times it had been forgotten and neglected, left to sit in the damp dark of a cellar, sat on and even used as a chopping board for a joint of beef. From this story Zoe and Royston began a complete reversal of their usual jobs as battlefield doctors, as undertakers and temple attendants; together we made Isaak's book, stitching and binding it, and then we began to simulate the infinitesimal, gradual torture which time enacts over hundreds of years. We had a few weeks.

I thought initially that the conservators would think me a bit kooky, or at the worst flippant about the difficult realities of their work. However to their credit they were as excited by the possibilities as I was, rejuvenated by this brief diversion from the Sisyphean task of patching, plastering and repairing. They took on the role of their nemesis with enthusiasm and began to pick apart what it was that made a book elderly or antique, where the beauty, rather than the nuisance, lay in that, and what stories they could tell separate from mine in the wrinkles, stains and folds of this old-not-old book. As every child everywhere knows, and we rediscovered, the best way to make a page look old is to dab it with a wet teabag; we didn't spare an inch of the book from the ministrations. The only element that we could not craft was that ambrosial, deathly smell of old paper. Apparently, the alchemy of that was beyond our skills.

The construction of the book took me to every corner of the Conservation Centre, and every facet of its work; from the handbinding cradles which made me feel as if I was lacing up somebody robust in a corset, to the storage rooms for the marbled paper which, when I went around opening the drawers and finding the ranked, swirling colours, seemed to me like a catalogue of oceans and explosions and nebulae. I met so many other talented artisans fighting the good fight, including Christina, the resident multispectral imaging minister. Her lab, a warm, silent sliver of a room filled with the always-drawn curtains, lamps and banks of machinery, has the air of an engine compartment, a police interrogation room and a disciplinary hearing in Westminster. It is here that the deepest, darkest corruptions of the Library's collections are revealed, at a microscopic detail that the Chilcot Inquiry can only dream of.

As I finish my time at the Library, and I grudgingly return my pass which got me through so many of the Centre's doors, I return to being a member of the public, a 'user' of the Library, with a realisation. As you can see, Zoe and Royston's work on my book is unequivocally art, not merely conservation. On display in the Lines In The Ice exhibition until the middle of April, our book sits alongside the 'true' artefacts of polar exploration almost imperceptibly, tricking the public without malice and camouflaging its story, its biography, amongst the degradation upon which the Library is built. In doing so it hijacks a small, respectful amount of the value, respect and meaning which the very old are due. The loveliness of this deception will be amplified when I finish Isaak's story, some day; then, the book will accessioned into the Library's archives, where it will begin to truly disintegrate rather than than just playing at it. One day even further in the future, the book will come back to its birthplace in the Conservation Centre, that squat building full of silent discourse and argument with the past, and plead its case.

It is in this way that I see the importance of the Centre's role at the Library taking on almost-legislative proportions. It is no secret that the public sector, of which the Library is a part, must now make do with less and less money as time goes on, even as the archives grow and the doddery old celebrities that they contain require even more work. The Conservation Centre is where such decisions on resources are made; it must be determined which books are to be rescued, where the hours will be spent and which items must, inevitably, wait until it is too late to save them. That book of Hebrew scripture was lucky, but in one hundred years Isaak's diary may not be as fortunate. It is a minor work, by three unheard-of artists. Who knows how difficult the choices that Cordelia's successor faces will be?

These thoughts are frightening ones, especially to those who believe in the immutability and the permanence of such collections. However, my time amongst the Conservation Centre's work has convinced me that such choices about what knowledge we shall retain and what shall be lost, and what will form the truth of the future, is being undertaken by the best people for the job. No matter how difficult time is to negotiate, how unbending and bullying, I know that the conservators will fight to make sure as much is saved as possible.

Even, I hope, those dog yoga books that I found in the archives, one bored Wednesday.

Rob Sherman

There are some binding styles that are inherently sound and will protect the texts within for centuries. In the West, generally they include sewing gatherings of bifolia through the fold with linen thread onto supports such as hemp cords, linen tapes, or slips of alum-tawed leather. Unfortunately, these methods tend to be expensive in time and materials. So the industrialisation of printing in the 19th century led also to new and varied means of holding the leaves together, most of them emphasising speed and cheapness over longevity.

The lowest-priced books had the crudest “sewing” – often stabbing holes through the entire textblock away from the spinefold to oversew the edge, or to pass through fasteners like staples or ties. One problem with this was that the leaves could not open conventionally at the spinefold, and quickly became damaged around the stab holes as readers tried to access text near the gutter.

Around 1880, a compromise was invented in Germany by which wire staples were inserted from inside through the spinefold onto supports such as tapes or cloth. This “wire sewing” seemed a fast and strong method, well suited to books that had to open well, such as music. Development of mechanised through-the-fold book-sewing machines began at about the same time, but took much longer to become economically viable. Thus wire sewing continued in use right through to the first half of the 20th century. Unfortunately, wire sewing has one serious flaw: the wires quickly rust and corrode both the book paper and the spine support. Eventually, they disintegrate and the book falls apart.

Photo 1: Rusalka (I.339.nn) as received in the conservation studio



Among the British Library’s printed music collections is a vocal score of Rusalka (I.339.nn), published in Moscow in 1937 – not the more familiar opera by Dvořák, but a lesser-known work in Russian by Alexander Dargomyzhsky (1813-1869). This was sent for conservation because the joints had split and the spine-cloth was detaching, but it was quickly apparent that it was wire sewn and much greater intervention was required.

Photo 2: a close-up of the damage to the spine



First, the wires had to be removed. The tines or legs of the staples were gently eased up on the outer spine. Fortunately, the cloth beneath them, though damaged, was intact enough to protect the spinefolds.

Photo 3: lifting the wires



Next the spine was gently rolled onto a length of plastazote ^(R) which the tines could sink into, both to stabilise the spine and protect the work-surface from scratches. The staples were then slowly worked out from the centre of each section, and the cloth forming the “sewing support” detached easily.

Photo 4: spine after cleaning, showing staggered holes left by the wire staples



Rust treatment was considered, but this is a lengthy and invasive action and it was found sufficient to brush out loose fragments from the sections. Minor tears to the textblock were repaired. The holes left by the wires were undamaged and could be used for resewing the textblock with linen thread. However they had been staggered on the spine to avoid bulking it at just a few points. One option was to sew through a textile spine lining, replicating the original support for the wires, but it was felt that triple linen tape supports at each station would better control the opening and eventually offer a stronger board attachment. Once this was done, a light spine lining was added.

Photo 5: resewn textblock detail



The old case was repaired, supporting the worn spine cloth and split joints. The corners also needed some attention to strengthen the soft, brittle boards and reform the split cloth covering them. Old marks and stains were left as they would not cause further damage and are part of the history of the item. Then textblock and case were rejoined.

Photo 6: the repaired case, drying



The final result is a music score that sits securely in its original case binding, with leaves that turn well and open flat should it ever be required for performance again.

Ann Tomalak

Digital archiving has hit the headlines recently, as people begin to worry publicly about our society’s digital memory.

Are they right to worry? As suggested by Google Boss Vint Cerf last week, it’s true that if you do nothing to manage and preserve your digital content, then it will inevitably fade away with time as the software and formats with which to read them become obsolete.

This is a particular concern for national institutions holding vast amounts of digital content, as we are charged with preserving digital assets in the very long term, for the next generations of future historians and researchers in centuries to come.

This endeavour, which we refer to as digital preservation, has been the subject of research in libraries and archives around the world for the past two decades and, reassuringly, there is much progress being made.

The British Library, like many national institutions, has a team dedicated to ensuring our collection of more than four million digital items is accessible indefinitely. The diversity of our digital collection makes this a huge challenge: we’ve got everything from web archives to eJournals and eBooks, digitised archives and manuscripts (including tens of thousands of emails), as well as datasets and huge collections of audio and video content. We don’t collect games, or mobile apps, and we leave archiving Twitter to the Library of Congress, but setting that aside, the collection is still incredibly diverse.

Our digital preservation team works closely with IT and curators on development of end-to end-preservation workflows for all of our digital collections. Our work is currently led by the strategic priorities laid out in our 2013-2016 Digital Preservation Strategy , underpinned by our twelve principles of digital preservation. We have a systematic approach to preserving our digital collections, because planning and preparation is essential to avoid being caught out as formats and technology disappear over time.

The digital collections are preserved in our purpose built Digital Library System, which replicates content across four storage nodes in different parts of the UK.

We have plans in place to make sure that these digital collections are not part of the ‘lost century’ that Vint is worried about; we’ll be monitoring format changes, assessing risks and establishing a technical registry and preservation watch system . This work is constant, because technology is changing all of the time.

At the same time, much of this content is being made available to researchers in the British Library’s Reading Rooms, and we’re investigating with academics how future historians will tackle this enormous resource, as well as how it might be curated.

We share expertise with other institutions in the UK through our work with the Digital Preservation Coalition, a non-profit membership organisation founded specifically to help institutions understand and address digital preservation challenges. We also take a leading role in the International Internet Preservation Consortium, which looks specifically at the challenges of web archiving, and which comprises over 50 members in 30 countries around the world.

Emulation and the use of ‘virtual machines’, which was one of the solutions proposed by Vint Cerf, may yet form part of our solution. Lots of work has been done in this area over the past decade, and our web archive technology already utilises an emulation solution within its Interject prototype for accessing resources in non-current formats.

At the end of the day though, preservation is much more than just a technical problem.
Preservation is about planning, it’s about management, it’s about process, it’s about permanence, and it’s about people. You need all of these things for preservation to happen. And that’s what we’re working on.

You might be wondering how this large-scale digital preservation work applies to your own personal digital content, like those collections of emails and photos we hold our desktops and hard drives. It’s early days, but it’s possible that in the future the expertise and solutions that we and others are developing will be adopted by commercial systems.

For now, just knowing which ones you want to keep, then keeping them accessible and backed up is a great start. More advice on this is available from the Library of Congress.

For further information about the work of the Library’s Digital Preservation team, visit the British Library website.

For more information about the Digital Preservation Coalition, visit their website at www.dpconline.org

Visit the British Library Living Knowledge webpage to learn more about making our intellectual heritage accessible to everyone, as we look ahead to 2023.

Maureen Pennock, Head of Digital Preservation

Meet Liz Rose, our newly appointed textile conservator!

I am Liz Rose and am the newly appointed textile conservator at the British Library. My role is to find and identify textiles within the diverse collections at the BL. I will build an asset register of textiles which will record the composition, size, condition and propose a treatment strategy or storage solution as well as compiling a glossary of terms to describe these objects.

In my first month I have been lucky enough to find a great many textiles within the collections. I have met with 16 specialist curators from the Asian and African; Contemporary British; Western Heritage and European and American collections. In total I have identified, condition checked, measured and photographed 53 culturally diverse objects. Here are some of the most memorable objects from January 2015:

• From the Burmese Collections I was shown a 20th century silk, talismanic shirt and trousers (1) and a palm leaf manuscript dated 1856 which is wrapped in cotton (2).



(1) OMS Or 15674







(2) OMS Or 12645







• From the Thai, Lao and Cambodia Collection, I was shown a 19th century talismanic shirt (3) from Shan community in Burma. This is highly decorated in black ink with mantras, number and yantra designs.



 (3) OMS Or 15085



• I was shown an escape map of Berlin made from waterproofed silk (4) (on the reverse a map of Germany). These maps would have been folded and sewn into the linings of uniforms.
• I also looked at a cotton ‘map of man’ (5) dated 1780 which displays ‘an allegorical map of human experience’, the border illustrating proverbs and instruction. It is quite large 732mm (w) x 685mm (h), printed in black and presumably engraved. Both these objects came from the Map Collections.

(4) Maps CC 5a 151



(5) Maps CC 6 a 27



• In the Printed Heritage Collections of Western Heritage, I found handbills dating from 1849 in natural silk (6) and pink silk dating from 1862 and 1867 (7) advertising theatre in Exeter. Some of these handbills are extremely fragile and discoloured from adhesive deposits whilst others look reasonably robust and remarkably clear.

(6) 74/L.R.412.e.4



(7) 74/L.R.412.e.4



• I also came across a pamphlet called ‘Uniform Rules and Regulations for the Cyclists’ Touring Club’. It contains illustrations of mens’ and womens’ cycling uniforms and two pages of textile samples: ‘Warranted Pure Wool’ (7) in three different weights for formal cycling wear and two weights of ‘Pure Sanitary Undyed Natural Wool for under-wear’.

(7) C.194.a.1105



• In the Radford Archive there is an embroidery by Frieda Lawrence (8), designed by D. H. Lawrence as a gift to their friends Maitland and Muriel Radford.

 (8) Add MS 89029/2/12

• From Medieval and Early Modern Manuscripts I was shown an 18th century embroidered binding (9) for the Birch-Yorke Letters (Vol. III). This is a bound collection of letters to Thomas Birch from some members of the Yorke family.
• I was also shown an illuminated manuscript, Yates, Thompson MS 31 (10), a large bound book in peach silk with lavish silver metal thread embroidery. This book dates from the last quarter of 14th century, the binding from 16th century and the embroidery from 18th century.

(9) Harley MS 4325



 (10) Yates, Thompson MS 31

I have only just started my research into textiles at the BL and have been overwhelmed by the quantity, quality and diversity of the textile objects within the collections. It should be remembered that the BL is a reference library and many of these wonderful objects can be viewed in the library Reading Rooms. However, a few of the examples included in this blog have limited or supervised access.

Liz Rose, Textile Conservator

Senior Imaging Technician Kristin A. Phelps takes us behind the scenes of the British Library’s Imaging Services where there are several ongoing digital projects at any given time.

Click here for an Arabic translation of this article, as translated by the Thesaurus Islamicus Foundation and Dar Al Kutub Manuscript Project.

Prior to the 14th Century, Byzantine artists who painted icons preferred to shun hubris and leave their works unsigned. Their work would be placed in churches to be seen and revered by thousands of the faithful over the centuries. Occasionally, an artist would sign their work with the phrase “Painted by the hand of a sinner.” This allowed the sacred value of the icon to remain unfettered by human presence.

Fast-forward to the modern world and a secular context: millions of digital images are accessed every day on websites of museums, libraries, archives and other collections. These images are taken by unseen photographers and are unsigned. The anonymity of the process allows for ‘pure’ and non-distracted understanding of the object by a viewer. But, who are these modern day artists who make invaluable works of art, faith and history accessible to all of us? How does their particular art form impact what we are able to view on our computer screens, tablets and smart phones?

To answer these questions we are going behind the scenes of the British Library’s Imaging Services where there are several ongoing digital projects at any given time. One project in particular, the Greek Manuscript Digitisation Project (GMDP), is working to digitise centuries old Greek manuscripts, some of which include illuminated portraits of the Evangelists executed by anonymous hands. The British Library’s third phase of the GMDP began in April 2014 and is scheduled to be completed March 2015 with a target of digitizing over 300 manuscripts, which is roughly equivalent to 120,000 images. The project has been funded by the Stavros Niarchos Foundation, the A.G. Leventis Foundation, Sam Goff, the Sylvia Iannou Foundation, the Thriplow Charitable Trust and the Friends of the British Library, among others.

The British Library’s Imaging Services currently employs eight full time photographers, or Senior Imaging Technicians, who represent approximately 110 years combined of photographic experience at the Library. While two of these photographers have been tasked with working on the GMDP, all of the photographers will work on the project at one point or another.

The eight photographers come from a variety of backgrounds including more traditional photographic backgrounds as well as artists, a former school teacher, a former 3D graphic designer with a specialty in computer gaming and a former archaeologist.

Once a book is delivered to the Imaging Studio, the physical digitisation process can begin. Every manuscript is unique and its physical condition can vary widely. For this reason, a conservation assessment is being performed for each manuscript to be imaged for any of the digitisation projects. This written report guides the photographer responsible for the book to ensure that manuscript is returned in the same condition it was received.

 Once the assessment has been read and understood, the manuscript is set up for capture on a cradle. Many manuscripts can be photographed using an L-shaped cradle, designed by the Conservation Department, to allow photography without damage to the material. When the manuscript has been appropriately set up, it can be photographed in RAW format page by page utilising Phase One cameras with digital backs.

Once the images are captured, they are reviewed and edited in Capture One (minor adjustments only including cropping, straightening and exposure adjustments).

Finally, the RAW files are processed into both Tiff and Jpeg files before being passed back to the various digital project teams for online publication.

Does this process sound simple and straightforward? It rarely is. Often times, a manuscript needs to be carefully propped up to become level, or has a page which is not flat. The photographer is then responsible for manipulating the manuscript with a very gentle and cautious manner to make the resulting image provide the best view of a page. In addition, items may be housed in glass which cannot be removed for imaging. Or, objects may be large and unwieldy or extremely small. Lighting conditions may need to be changed if the manuscript contains significant amounts of gold leaf decoration. And, of course, there are always physical adjustments of the camera position and settings as well as employing a variety of lenses. Throughout the process the photographers have to use their judgment and experience in order to “do no harm” and yield images that represent faithfully the original material. After observing everything which must be considered to photograph a manuscript, the question arises: are these professionals artists or technicians? The Library photographers themselves are split when it comes to answering this question. Half of them consider their particular type of photography an art form whilst the rest view it as form of scientific imaging.

No matter what the answer to this question is, one thing is certain. These photographers deliver an impactful and important volume of work to the digital masses. Scholars from across the world have advanced their research without the need to physically visit the British Library. Thousands of people are able to connect with global cultural and religious heritage with a click of a button.

Of course, the GMDP project is just one example of a common wider trend of museums, libraries and archives digitising their holdings for online publication. In Europe alone as of 2014, 87% of cultural heritage institutions had digital collections. ENUMERATE’s 2014 survey found that the most important perceived reason for digital collections was academic research, which points to the growing field of Digital Humanities. With all the new material available online, a visual revolution of the democratisation of knowledge is happening. Now a scholar is no longer hindered by the inability to travel afar to libraries and museums to see objects; instant access to manuscripts and 3D objects is only a click away. Scholarship is becoming more diverse because open access to online collections allows those who wish to see something to be able to do just that. In fact, in its still young life, the third phase of the GMDP has already been the focus of scholarly research as well as being used and shared by a number of New Testament and Patristic blogs.

Of course, none of this would be possible without the diligent and specialised work of the photographers at institutions like the British Library. But if you asked one of the British Library Imaging Services’ photographers about their role in the process you receive humble responses, not dissimilar to what you would have expected from the original “sinners.”

Kristin A. Phelps, Senior Imaging Technician
